| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_127T02_9000001522_10507cztM0_level2.evt | modeM0/AS1A03_127T02_9000001522_10507cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,455,360 | 126,195,840 |
| Size | 476.3 MB | 120.3 MB |
| Events in quadrant A | 3,384,460 | 841,544 |
| Events in quadrant B | 4,595,246 | 832,875 |
| Events in quadrant C | 2,953,539 | 884,081 |
| Events in quadrant D | 3,768,629 | 827,392 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 22 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14025 | 3 |
| B | 0 | 17821 | 2 |
| C | 0 | 12809 | 2 |
| D | 0 | 15269 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6253 | 95 | 1.519271% |
| B | 6253 | 646 | 10.331041% |
| C | 6253 | 12 | 0.191908% |
| D | 6253 | 69 | 1.103470% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7558 | 6254 | 55 | 55 | 0.73% | 0.88% |  |
| B | 7558 | 6254 | 434 | 434 | 5.74% | 6.94% |  |
| C | 7558 | 6254 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7558 | 6254 | 47 | 47 | 0.62% | 0.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 238077 | 1587.56 | 749 | 734 | 149.5 |
| A | 15 | 174 | 179483 | 1195.63 | 749 | 734 | 149.5 |
| A | 3 | 80 | 55137 | 363.9 | 749 | 734 | 149.5 |
| B | 4 | 239 | 1474227 | 10818.14 | 736 | 718 | 136.2 |
| B | 0 | 214 | 105750 | 771.12 | 736 | 718 | 136.2 |
| B | 11 | 51 | 50855 | 368.09 | 736 | 718 | 136.2 |
| C | 13 | 61 | 5662 | 28.55 | 756 | 760 | 171.7 |
| C | 14 | 234 | 2116 | 7.9 | 756 | 760 | 171.7 |
| C | 3 | 202 | 1883 | 6.54 | 756 | 760 | 171.7 |
| D | 2 | 16 | 455872 | 2595.66 | 739 | 722 | 175.4 |
| D | 8 | 195 | 220436 | 1253.0 | 739 | 722 | 175.4 |
| D | 5 | 222 | 77416 | 437.38 | 739 | 722 | 175.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
