| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_004T01_9000001532_10567cztM0_level2.evt | modeM0/AS1G07_004T01_9000001532_10567cztM0_level2_quad_clean.evt |
| Size (bytes) | 474,825,600 | 91,869,120 |
| Size | 452.8 MB | 87.6 MB |
| Events in quadrant A | 3,007,116 | 571,705 |
| Events in quadrant B | 3,757,081 | 592,136 |
| Events in quadrant C | 3,000,196 | 602,396 |
| Events in quadrant D | 4,169,834 | 558,052 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13497 | 15 |
| B | 0 | 15547 | 10 |
| C | 0 | 13556 | 4 |
| D | 0 | 16848 | 19 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6572 | 12 | 0.182593% |
| B | 6573 | 200 | 3.042751% |
| C | 6576 | 9 | 0.136861% |
| D | 6571 | 90 | 1.369655% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7864 | 6579 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7864 | 6579 | 95 | 95 | 1.21% | 1.44% |  |
| C | 7864 | 6579 | 3 | 3 | 0.04% | 0.05% |  |
| D | 7864 | 6579 | 81 | 81 | 1.03% | 1.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 26288 | 164.74 | 765 | 751 | 155.0 |
| A | 13 | 251 | 16671 | 102.7 | 765 | 751 | 155.0 |
| A | 1 | 161 | 7040 | 40.57 | 765 | 751 | 155.0 |
| B | 4 | 239 | 652610 | 4454.68 | 773 | 756 | 146.3 |
| B | 0 | 214 | 30489 | 203.19 | 773 | 756 | 146.3 |
| B | 0 | 219 | 30109 | 200.59 | 773 | 756 | 146.3 |
| C | 14 | 234 | 40737 | 229.53 | 758 | 764 | 174.1 |
| C | 13 | 61 | 5753 | 28.65 | 758 | 764 | 174.1 |
| C | 4 | 175 | 2592 | 10.5 | 758 | 764 | 174.1 |
| D | 2 | 16 | 613826 | 3479.94 | 738 | 717 | 176.2 |
| D | 12 | 233 | 565364 | 3204.87 | 738 | 717 | 176.2 |
| D | 8 | 195 | 121532 | 685.73 | 738 | 717 | 176.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
