| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_046T01_9000001534_10580cztM0_level2.evt | modeM0/AS1G07_046T01_9000001534_10580cztM0_level2_quad_clean.evt |
| Size (bytes) | 499,507,200 | 88,891,200 |
| Size | 476.4 MB | 84.8 MB |
| Events in quadrant A | 3,082,032 | 579,773 |
| Events in quadrant B | 5,066,344 | 562,705 |
| Events in quadrant C | 2,992,914 | 576,503 |
| Events in quadrant D | 3,562,912 | 537,180 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13072 | 3 |
| B | 0 | 19096 | 2 |
| C | 0 | 12891 | 2 |
| D | 0 | 14667 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6243 | 45 | 0.720807% |
| B | 6243 | 647 | 10.363607% |
| C | 6243 | 14 | 0.224251% |
| D | 6243 | 25 | 0.400449% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7548 | 6244 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7548 | 6244 | 503 | 503 | 6.66% | 8.06% |  |
| C | 7548 | 6244 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7548 | 6244 | 1 | 1 | 0.01% | 0.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 35823 | 222.46 | 782 | 768 | 157.6 |
| A | 1 | 162 | 17414 | 105.64 | 782 | 768 | 157.6 |
| A | 0 | 226 | 7247 | 41.12 | 782 | 768 | 157.6 |
| B | 4 | 239 | 1783745 | 12288.11 | 768 | 752 | 145.1 |
| B | 0 | 219 | 137986 | 945.8 | 768 | 752 | 145.1 |
| B | 11 | 51 | 53414 | 362.94 | 768 | 752 | 145.1 |
| C | 4 | 175 | 17171 | 92.91 | 761 | 769 | 176.5 |
| C | 13 | 61 | 5846 | 28.76 | 761 | 769 | 176.5 |
| C | 14 | 234 | 4871 | 23.24 | 761 | 769 | 176.5 |
| D | 2 | 16 | 505516 | 2865.1 | 743 | 724 | 176.2 |
| D | 8 | 195 | 169539 | 958.16 | 743 | 724 | 176.2 |
| D | 2 | 234 | 23260 | 127.91 | 743 | 724 | 176.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
