| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_191T01_9000001536_10597cztM0_level2.evt | modeM0/AS1T01_191T01_9000001536_10597cztM0_level2_quad_clean.evt |
| Size (bytes) | 569,286,720 | 76,642,560 |
| Size | 542.9 MB | 73.1 MB |
| Events in quadrant A | 3,633,978 | 460,038 |
| Events in quadrant B | 4,757,832 | 475,084 |
| Events in quadrant C | 3,595,121 | 470,791 |
| Events in quadrant D | 4,786,672 | 433,982 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15368 | 3 |
| B | 0 | 18572 | 2 |
| C | 0 | 15297 | 2 |
| D | 0 | 18975 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6896 | 207 | 3.001740% |
| B | 6896 | 417 | 6.046984% |
| C | 6896 | 189 | 2.740719% |
| D | 6896 | 232 | 3.364269% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7901 | 6897 | 172 | 172 | 2.18% | 2.49% |  |
| B | 7901 | 6897 | 232 | 232 | 2.94% | 3.36% |  |
| C | 7901 | 6897 | 175 | 175 | 2.21% | 2.54% |  |
| D | 7901 | 6897 | 228 | 228 | 2.89% | 3.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 9120 | 41.14 | 938 | 924 | 199.2 |
| A | 0 | 226 | 8431 | 37.68 | 938 | 924 | 199.2 |
| A | 12 | 194 | 7873 | 34.88 | 938 | 924 | 199.2 |
| B | 4 | 239 | 1113331 | 6461.28 | 898 | 882 | 172.2 |
| B | 4 | 81 | 64491 | 369.45 | 898 | 882 | 172.2 |
| B | 0 | 214 | 37644 | 213.52 | 898 | 882 | 172.2 |
| C | 14 | 234 | 9488 | 38.74 | 918 | 929 | 221.0 |
| C | 13 | 61 | 6516 | 25.29 | 918 | 929 | 221.0 |
| C | 4 | 175 | 4507 | 16.19 | 918 | 929 | 221.0 |
| D | 2 | 16 | 571616 | 2490.47 | 921 | 901 | 229.2 |
| D | 8 | 195 | 530490 | 2311.01 | 921 | 901 | 229.2 |
| D | 1 | 52 | 68748 | 296.07 | 921 | 901 | 229.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
