| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_191T01_9000001536_10626cztM0_level2.evt | modeM0/AS1T01_191T01_9000001536_10626cztM0_level2_quad_clean.evt |
| Size (bytes) | 510,995,520 | 81,780,480 |
| Size | 487.3 MB | 78.0 MB |
| Events in quadrant A | 3,218,780 | 509,959 |
| Events in quadrant B | 4,297,621 | 509,029 |
| Events in quadrant C | 3,145,687 | 514,765 |
| Events in quadrant D | 4,363,610 | 480,289 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13799 | 3 |
| B | 0 | 17126 | 2 |
| C | 0 | 13807 | 2 |
| D | 0 | 17382 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6640 | 50 | 0.753012% |
| B | 6640 | 255 | 3.840361% |
| C | 6640 | 37 | 0.557229% |
| D | 6640 | 130 | 1.957831% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7580 | 6641 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7580 | 6641 | 114 | 114 | 1.50% | 1.72% |  |
| C | 7580 | 6641 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7580 | 6641 | 46 | 46 | 0.61% | 0.69% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 66055 | 400.22 | 798 | 785 | 163.1 |
| A | 1 | 162 | 39260 | 235.92 | 798 | 785 | 163.1 |
| A | 1 | 178 | 14103 | 81.66 | 798 | 785 | 163.1 |
| B | 4 | 239 | 973370 | 6425.52 | 796 | 782 | 151.4 |
| B | 0 | 219 | 98493 | 645.54 | 796 | 782 | 151.4 |
| B | 0 | 214 | 67811 | 442.83 | 796 | 782 | 151.4 |
| C | 4 | 254 | 76873 | 422.04 | 779 | 787 | 180.3 |
| C | 14 | 234 | 13339 | 69.62 | 779 | 787 | 180.3 |
| C | 12 | 4 | 11466 | 59.24 | 779 | 787 | 180.3 |
| D | 1 | 52 | 529176 | 2864.74 | 765 | 745 | 184.5 |
| D | 2 | 16 | 496213 | 2686.04 | 765 | 745 | 184.5 |
| D | 8 | 195 | 157613 | 850.41 | 765 | 745 | 184.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
