| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_191T01_9000001536_10656cztM0_level2.evt | modeM0/AS1T01_191T01_9000001536_10656cztM0_level2_quad_clean.evt |
| Size (bytes) | 620,112,960 | 88,243,200 |
| Size | 591.4 MB | 84.2 MB |
| Events in quadrant A | 4,005,330 | 555,879 |
| Events in quadrant B | 4,618,341 | 550,004 |
| Events in quadrant C | 4,204,061 | 548,588 |
| Events in quadrant D | 5,468,012 | 519,301 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16632 | 4 |
| B | 0 | 18424 | 3 |
| C | 0 | 17478 | 3 |
| D | 0 | 21019 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7147 | 294 | 4.113614% |
| B | 7147 | 416 | 5.820624% |
| C | 7147 | 363 | 5.079054% |
| D | 7147 | 383 | 5.358892% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7602 | 7149 | 140 | 140 | 1.84% | 1.96% |  |
| B | 7602 | 7149 | 161 | 161 | 2.12% | 2.25% |  |
| C | 7602 | 7149 | 193 | 193 | 2.54% | 2.70% |  |
| D | 7602 | 7149 | 308 | 308 | 4.05% | 4.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 502577 | 2851.28 | 848 | 831 | 176.0 |
| A | 4 | 2 | 110119 | 621.05 | 848 | 831 | 176.0 |
| A | 15 | 223 | 51893 | 290.17 | 848 | 831 | 176.0 |
| B | 4 | 239 | 974600 | 5954.48 | 848 | 830 | 163.5 |
| B | 10 | 245 | 165054 | 1004.21 | 848 | 830 | 163.5 |
| B | 15 | 204 | 86343 | 522.9 | 848 | 830 | 163.5 |
| C | 4 | 254 | 972973 | 5091.98 | 822 | 831 | 190.9 |
| C | 14 | 234 | 10558 | 50.95 | 822 | 831 | 190.9 |
| C | 14 | 67 | 6383 | 29.08 | 822 | 831 | 190.9 |
| D | 1 | 20 | 1291816 | 6478.34 | 814 | 792 | 199.3 |
| D | 14 | 34 | 648756 | 3251.47 | 814 | 792 | 199.3 |
| D | 8 | 195 | 164163 | 819.79 | 814 | 792 | 199.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
