| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_053T01_9000001542_10710cztM0_level2.evt | modeM0/AS1A03_053T01_9000001542_10710cztM0_level2_quad_clean.evt |
| Size (bytes) | 518,042,880 | 89,997,120 |
| Size | 494.0 MB | 85.8 MB |
| Events in quadrant A | 3,201,362 | 593,326 |
| Events in quadrant B | 4,752,787 | 580,378 |
| Events in quadrant C | 3,048,662 | 578,947 |
| Events in quadrant D | 4,262,570 | 536,545 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13543 | 3 |
| B | 0 | 18167 | 2 |
| C | 0 | 13290 | 2 |
| D | 0 | 16761 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6244 | 57 | 0.912876% |
| B | 6244 | 394 | 6.310058% |
| C | 6244 | 40 | 0.640615% |
| D | 6245 | 68 | 1.088871% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7579 | 6245 | 14 | 14 | 0.18% | 0.22% |  |
| B | 7579 | 6245 | 278 | 278 | 3.67% | 4.45% |  |
| C | 7579 | 6245 | 18 | 18 | 0.24% | 0.29% |  |
| D | 7580 | 6246 | 39 | 39 | 0.51% | 0.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 61687 | 380.31 | 790 | 776 | 160.2 |
| A | 1 | 162 | 37602 | 229.93 | 790 | 776 | 160.2 |
| A | 11 | 29 | 13758 | 81.05 | 790 | 776 | 160.2 |
| B | 4 | 239 | 1576066 | 10669.18 | 778 | 763 | 147.6 |
| B | 15 | 204 | 61825 | 413.56 | 778 | 763 | 147.6 |
| B | 0 | 214 | 40114 | 266.52 | 778 | 763 | 147.6 |
| C | 4 | 254 | 106326 | 606.35 | 752 | 758 | 174.1 |
| C | 13 | 61 | 5838 | 29.18 | 752 | 758 | 174.1 |
| C | 14 | 67 | 4085 | 19.11 | 752 | 758 | 174.1 |
| D | 2 | 16 | 713447 | 3991.33 | 743 | 723 | 178.6 |
| D | 7 | 71 | 228008 | 1272.82 | 743 | 723 | 178.6 |
| D | 8 | 195 | 214979 | 1199.86 | 743 | 723 | 178.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
