| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_078T01_9000001546_10742cztM0_level2.evt | modeM0/AS1A03_078T01_9000001546_10742cztM0_level2_quad_clean.evt |
| Size (bytes) | 642,168,000 | 95,031,360 |
| Size | 612.4 MB | 90.6 MB |
| Events in quadrant A | 3,445,869 | 613,932 |
| Events in quadrant B | 4,413,630 | 621,491 |
| Events in quadrant C | 3,265,520 | 626,715 |
| Events in quadrant D | 7,850,172 | 528,452 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15019 | 3 |
| B | 0 | 17873 | 2 |
| C | 0 | 14486 | 2 |
| D | 0 | 28174 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6979 | 67 | 0.960023% |
| B | 6979 | 326 | 4.671156% |
| C | 6979 | 28 | 0.401204% |
| D | 6979 | 1323 | 18.956871% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9174 | 6981 | 16 | 16 | 0.17% | 0.23% |  |
| B | 9174 | 6981 | 136 | 136 | 1.48% | 1.95% |  |
| C | 9174 | 6981 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9174 | 6980 | 1121 | 1121 | 12.22% | 16.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 239 | 88989 | 507.43 | 845 | 825 | 173.7 |
| A | 14 | 254 | 52031 | 294.72 | 845 | 825 | 173.7 |
| A | 15 | 174 | 18553 | 102.03 | 845 | 825 | 173.7 |
| B | 4 | 239 | 892979 | 5478.21 | 848 | 827 | 162.9 |
| B | 0 | 214 | 113350 | 690.94 | 848 | 827 | 162.9 |
| B | 15 | 204 | 44753 | 269.73 | 848 | 827 | 162.9 |
| C | 13 | 61 | 6226 | 27.79 | 836 | 841 | 193.8 |
| C | 14 | 67 | 3315 | 12.77 | 836 | 841 | 193.8 |
| C | 3 | 202 | 2068 | 6.33 | 836 | 841 | 193.8 |
| D | 2 | 16 | 3866716 | 21109.65 | 757 | 736 | 183.1 |
| D | 1 | 52 | 583731 | 3183.36 | 757 | 736 | 183.1 |
| D | 10 | 172 | 237499 | 1292.81 | 757 | 736 | 183.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
