| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_086T01_9000001568_10830cztM0_level2.evt | modeM0/AS1A03_086T01_9000001568_10830cztM0_level2_quad_clean.evt |
| Size (bytes) | 576,529,920 | 94,083,840 |
| Size | 549.8 MB | 89.7 MB |
| Events in quadrant A | 5,471,700 | 589,314 |
| Events in quadrant B | 4,374,197 | 602,328 |
| Events in quadrant C | 3,162,751 | 608,307 |
| Events in quadrant D | 3,990,323 | 574,694 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20837 | 2 |
| B | 0 | 17390 | 1 |
| C | 0 | 13923 | 1 |
| D | 0 | 16628 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6808 | 531 | 7.799647% |
| B | 6808 | 290 | 4.259694% |
| C | 6808 | 39 | 0.572855% |
| D | 6808 | 116 | 1.703878% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7253 | 6809 | 367 | 367 | 5.06% | 5.39% |  |
| B | 7253 | 6809 | 147 | 147 | 2.03% | 2.16% |  |
| C | 7253 | 6809 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7253 | 6809 | 52 | 52 | 0.72% | 0.76% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 2329831 | 14159.16 | 802 | 786 | 164.5 |
| A | 13 | 251 | 41964 | 250.34 | 802 | 786 | 164.5 |
| A | 11 | 29 | 7683 | 41.93 | 802 | 786 | 164.5 |
| B | 4 | 239 | 1017957 | 6416.85 | 822 | 804 | 158.5 |
| B | 4 | 173 | 36232 | 223.5 | 822 | 804 | 158.5 |
| B | 0 | 214 | 36129 | 222.85 | 822 | 804 | 158.5 |
| C | 14 | 234 | 13819 | 69.22 | 807 | 816 | 187.8 |
| C | 13 | 61 | 5939 | 27.27 | 807 | 816 | 187.8 |
| C | 8 | 222 | 2734 | 10.21 | 807 | 816 | 187.8 |
| D | 8 | 195 | 434781 | 2245.91 | 800 | 778 | 193.2 |
| D | 12 | 233 | 130039 | 668.91 | 800 | 778 | 193.2 |
| D | 1 | 52 | 71797 | 367.51 | 800 | 778 | 193.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
