| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A03_086T01_9000001568_10840cztM0_level2.evt | modeM0/AS1A03_086T01_9000001568_10840cztM0_level2_quad_clean.evt |
| Size (bytes) | 555,177,600 | 78,629,760 |
| Size | 529.5 MB | 75.0 MB |
| Events in quadrant A | 4,314,313 | 485,704 |
| Events in quadrant B | 4,973,130 | 482,872 |
| Events in quadrant C | 3,330,123 | 488,122 |
| Events in quadrant D | 3,747,549 | 462,751 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17123 | 3 |
| B | 0 | 19077 | 2 |
| C | 0 | 13877 | 2 |
| D | 0 | 15265 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6618 | 200 | 3.022061% |
| B | 6618 | 520 | 7.857359% |
| C | 6618 | 64 | 0.967060% |
| D | 6618 | 147 | 2.221215% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7859 | 6619 | 75 | 75 | 0.95% | 1.13% |  |
| B | 7859 | 6619 | 289 | 289 | 3.68% | 4.37% |  |
| C | 7859 | 6619 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7859 | 6620 | 60 | 60 | 0.76% | 0.91% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 786845 | 4456.48 | 877 | 863 | 176.4 |
| A | 13 | 251 | 103354 | 581.12 | 877 | 863 | 176.4 |
| A | 15 | 174 | 23268 | 127.03 | 877 | 863 | 176.4 |
| B | 4 | 239 | 1395624 | 8779.3 | 856 | 840 | 158.9 |
| B | 3 | 189 | 147426 | 922.67 | 856 | 840 | 158.9 |
| B | 0 | 214 | 55642 | 344.94 | 856 | 840 | 158.9 |
| C | 13 | 61 | 6253 | 27.54 | 852 | 859 | 195.8 |
| C | 14 | 234 | 4372 | 17.94 | 852 | 859 | 195.8 |
| C | 7 | 238 | 2607 | 8.93 | 852 | 859 | 195.8 |
| D | 13 | 104 | 117931 | 575.94 | 851 | 830 | 203.3 |
| D | 2 | 14 | 101704 | 496.13 | 851 | 830 | 203.3 |
| D | 13 | 138 | 60263 | 292.31 | 851 | 830 | 203.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
