| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_055T01_9000001574_10897cztM0_level2.evt | modeM0/AS1A04_055T01_9000001574_10897cztM0_level2_quad_clean.evt |
| Size (bytes) | 602,948,160 | 112,538,880 |
| Size | 575.0 MB | 107.3 MB |
| Events in quadrant A | 6,760,828 | 666,015 |
| Events in quadrant B | 4,364,544 | 773,946 |
| Events in quadrant C | 3,086,599 | 783,763 |
| Events in quadrant D | 3,618,494 | 741,496 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24358 | 3 |
| B | 0 | 17309 | 2 |
| C | 0 | 13447 | 2 |
| D | 0 | 14842 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6344 | 1514 | 23.865069% |
| B | 6344 | 391 | 6.163304% |
| C | 6344 | 64 | 1.008827% |
| D | 6344 | 132 | 2.080706% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7524 | 6344 | 1075 | 1075 | 14.29% | 16.95% |  |
| B | 7524 | 6344 | 177 | 177 | 2.35% | 2.79% |  |
| C | 7524 | 6344 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7524 | 6344 | 34 | 34 | 0.45% | 0.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 3843778 | 26422.18 | 714 | 701 | 145.4 |
| A | 13 | 210 | 142443 | 974.51 | 714 | 701 | 145.4 |
| A | 1 | 162 | 6801 | 41.94 | 714 | 701 | 145.4 |
| B | 4 | 239 | 1046253 | 7033.58 | 794 | 776 | 148.6 |
| B | 0 | 214 | 77790 | 518.12 | 794 | 776 | 148.6 |
| B | 4 | 81 | 71203 | 473.81 | 794 | 776 | 148.6 |
| C | 13 | 61 | 5884 | 28.38 | 789 | 794 | 179.4 |
| C | 8 | 222 | 4598 | 21.21 | 789 | 794 | 179.4 |
| C | 14 | 67 | 2195 | 7.81 | 789 | 794 | 179.4 |
| D | 9 | 85 | 122613 | 653.34 | 790 | 770 | 186.5 |
| D | 13 | 152 | 90682 | 482.12 | 790 | 770 | 186.5 |
| D | 13 | 249 | 80454 | 427.27 | 790 | 770 | 186.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
