| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_109T01_9000001578_10916cztM0_level2.evt | modeM0/AS1A04_109T01_9000001578_10916cztM0_level2_quad_clean.evt |
| Size (bytes) | 352,385,280 | 54,685,440 |
| Size | 336.1 MB | 52.2 MB |
| Events in quadrant A | 2,935,040 | 335,498 |
| Events in quadrant B | 3,059,125 | 338,827 |
| Events in quadrant C | 2,014,045 | 342,769 |
| Events in quadrant D | 2,361,694 | 326,565 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 90 | 0 |
| B | 0 | 90 | 2 |
| C | 0 | 90 | 0 |
| D | 0 | 90 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11601 | 11 |
| B | 0 | 12029 | 4 |
| C | 0 | 9121 | 5 |
| D | 0 | 10206 | 5 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4438 | 228 | 5.137449% |
| B | 4441 | 298 | 6.710200% |
| C | 4440 | 13 | 0.292793% |
| D | 4440 | 56 | 1.261261% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5162 | 4443 | 136 | 136 | 2.63% | 3.06% |  |
| B | 5162 | 4443 | 151 | 151 | 2.93% | 3.40% |  |
| C | 5162 | 4443 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5162 | 4443 | 30 | 30 | 0.58% | 0.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 592626 | 5509.9 | 523 | 510 | 107.5 |
| A | 8 | 5 | 248755 | 2310.03 | 523 | 510 | 107.5 |
| A | 15 | 223 | 35707 | 327.52 | 523 | 510 | 107.5 |
| B | 4 | 239 | 915039 | 9055.61 | 526 | 514 | 101.0 |
| B | 0 | 214 | 43681 | 427.44 | 526 | 514 | 101.0 |
| B | 0 | 219 | 15863 | 151.99 | 526 | 514 | 101.0 |
| C | 13 | 61 | 3898 | 27.91 | 515 | 518 | 121.1 |
| C | 8 | 222 | 2352 | 15.14 | 515 | 518 | 121.1 |
| C | 3 | 202 | 1310 | 6.54 | 515 | 518 | 121.1 |
| D | 5 | 222 | 205495 | 1646.14 | 511 | 496 | 124.5 |
| D | 1 | 52 | 126713 | 1013.52 | 511 | 496 | 124.5 |
| D | 7 | 71 | 24382 | 191.8 | 511 | 496 | 124.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
