| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_039T01_9000001582_10930cztM0_level2.evt | modeM0/AS1G08_039T01_9000001582_10930cztM0_level2_quad_clean.evt |
| Size (bytes) | 440,337,600 | 77,437,440 |
| Size | 419.9 MB | 73.9 MB |
| Events in quadrant A | 3,410,443 | 486,939 |
| Events in quadrant B | 3,658,009 | 491,728 |
| Events in quadrant C | 2,693,701 | 483,704 |
| Events in quadrant D | 3,165,130 | 462,790 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14069 | 2 |
| B | 0 | 14814 | 1 |
| C | 0 | 12328 | 1 |
| D | 0 | 13406 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6008 | 174 | 2.896138% |
| B | 6008 | 297 | 4.943409% |
| C | 6008 | 36 | 0.599201% |
| D | 6008 | 60 | 0.998668% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6928 | 6009 | 81 | 81 | 1.17% | 1.35% |  |
| B | 6928 | 6009 | 137 | 137 | 1.98% | 2.28% |  |
| C | 6928 | 6009 | 1 | 1 | 0.01% | 0.02% |  |
| D | 6928 | 6009 | 19 | 19 | 0.27% | 0.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 481720 | 3295.08 | 712 | 697 | 146.0 |
| A | 15 | 223 | 87151 | 592.22 | 712 | 697 | 146.0 |
| A | 15 | 239 | 26622 | 177.59 | 712 | 697 | 146.0 |
| B | 4 | 239 | 790805 | 5830.94 | 710 | 695 | 135.5 |
| B | 4 | 81 | 45750 | 332.5 | 710 | 695 | 135.5 |
| B | 15 | 204 | 16778 | 118.69 | 710 | 695 | 135.5 |
| C | 7 | 205 | 7126 | 40.09 | 685 | 686 | 160.7 |
| C | 12 | 4 | 6613 | 36.89 | 685 | 686 | 160.7 |
| C | 13 | 61 | 5297 | 28.7 | 685 | 686 | 160.7 |
| D | 8 | 195 | 330614 | 1982.57 | 685 | 666 | 166.4 |
| D | 13 | 104 | 61268 | 364.14 | 685 | 666 | 166.4 |
| D | 1 | 52 | 45427 | 268.96 | 685 | 666 | 166.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
