| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_193T01_9000001590_10954cztM0_level2.evt | modeM0/AS1T01_193T01_9000001590_10954cztM0_level2_quad_clean.evt |
| Size (bytes) | 117,192,960 | 32,267,520 |
| Size | 111.8 MB | 30.8 MB |
| Events in quadrant A | 934,303 | 217,826 |
| Events in quadrant B | 817,351 | 221,841 |
| Events in quadrant C | 695,998 | 220,443 |
| Events in quadrant D | 1,000,146 | 208,913 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28 | 0 |
| B | 0 | 28 | 0 |
| C | 0 | 28 | 0 |
| D | 0 | 28 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3801 | 2 |
| B | 0 | 3345 | 1 |
| C | 0 | 2995 | 1 |
| D | 0 | 3908 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1456 | 14 | 0.961538% |
| B | 1456 | 39 | 2.678571% |
| C | 1456 | 3 | 0.206044% |
| D | 1456 | 42 | 2.884615% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 1456 | 1456 | 2 | 2 | 0.14% | 0.14% |  |
| B | 1456 | 1456 | 15 | 15 | 1.03% | 1.03% |  |
| C | 1456 | 1456 | 0 | 0 | 0.00% | 0.00% |  |
| D | 1456 | 1456 | 30 | 30 | 2.06% | 2.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 146754 | 3708.32 | 185 | 182 | 39.5 |
| A | 8 | 5 | 65025 | 1640.55 | 185 | 182 | 39.5 |
| A | 11 | 29 | 6514 | 160.2 | 185 | 182 | 39.5 |
| B | 4 | 239 | 91318 | 2475.5 | 186 | 183 | 36.8 |
| B | 12 | 111 | 3788 | 97.92 | 186 | 183 | 36.8 |
| B | 11 | 111 | 2882 | 73.31 | 186 | 183 | 36.8 |
| C | 12 | 4 | 1482 | 30.84 | 177 | 179 | 42.3 |
| C | 13 | 61 | 1319 | 26.98 | 177 | 179 | 42.3 |
| C | 5 | 207 | 842 | 15.69 | 177 | 179 | 42.3 |
| D | 1 | 52 | 240147 | 5581.53 | 174 | 170 | 43.0 |
| D | 8 | 195 | 33034 | 764.37 | 174 | 170 | 43.0 |
| D | 13 | 104 | 29717 | 687.22 | 174 | 170 | 43.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
