| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_027T06_9000001594_11000cztM0_level2.evt | modeM0/AS1G08_027T06_9000001594_11000cztM0_level2_quad_clean.evt |
| Size (bytes) | 525,551,040 | 95,195,520 |
| Size | 501.2 MB | 90.8 MB |
| Events in quadrant A | 3,906,472 | 628,554 |
| Events in quadrant B | 4,560,745 | 617,316 |
| Events in quadrant C | 3,178,928 | 617,993 |
| Events in quadrant D | 3,848,332 | 584,476 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15808 | 3 |
| B | 0 | 17693 | 2 |
| C | 0 | 13330 | 2 |
| D | 0 | 15347 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6226 | 136 | 2.184388% |
| B | 6226 | 446 | 7.163508% |
| C | 6226 | 49 | 0.787022% |
| D | 6226 | 113 | 1.814969% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7581 | 6227 | 52 | 52 | 0.69% | 0.84% |  |
| B | 7581 | 6227 | 255 | 255 | 3.36% | 4.10% |  |
| C | 7581 | 6227 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7581 | 6227 | 54 | 54 | 0.71% | 0.87% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 383696 | 2250.44 | 852 | 837 | 170.1 |
| A | 15 | 174 | 176973 | 1035.33 | 852 | 837 | 170.1 |
| A | 14 | 254 | 42249 | 243.42 | 852 | 837 | 170.1 |
| B | 4 | 239 | 1166950 | 7600.04 | 827 | 812 | 153.4 |
| B | 0 | 214 | 47994 | 307.5 | 827 | 812 | 153.4 |
| B | 3 | 189 | 44605 | 285.41 | 827 | 812 | 153.4 |
| C | 13 | 61 | 6069 | 28.39 | 814 | 821 | 184.8 |
| C | 12 | 4 | 2601 | 9.63 | 814 | 821 | 184.8 |
| C | 14 | 234 | 2213 | 7.53 | 814 | 821 | 184.8 |
| D | 1 | 52 | 324523 | 1669.12 | 815 | 795 | 194.0 |
| D | 13 | 104 | 117453 | 601.48 | 815 | 795 | 194.0 |
| D | 5 | 222 | 72967 | 372.11 | 815 | 795 | 194.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
