| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_004T01_9000001598_11014cztM0_level2.evt | modeM0/AS1C03_004T01_9000001598_11014cztM0_level2_quad_clean.evt |
| Size (bytes) | 631,978,560 | 99,285,120 |
| Size | 602.7 MB | 94.7 MB |
| Events in quadrant A | 7,824,146 | 565,117 |
| Events in quadrant B | 3,807,296 | 687,412 |
| Events in quadrant C | 2,920,292 | 698,504 |
| Events in quadrant D | 4,191,366 | 645,510 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27365 | 2 |
| B | 0 | 14876 | 1 |
| C | 0 | 12273 | 1 |
| D | 0 | 16448 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5864 | 1691 | 28.836971% |
| B | 5864 | 278 | 4.740791% |
| C | 5864 | 26 | 0.443383% |
| D | 5864 | 190 | 3.240109% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7183 | 5863 | 1357 | 1357 | 18.89% | 23.15% |  |
| B | 7184 | 5864 | 165 | 165 | 2.30% | 2.81% |  |
| C | 7184 | 5865 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7184 | 5865 | 144 | 144 | 2.00% | 2.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 4729723 | 36085.1 | 655 | 643 | 131.1 |
| A | 8 | 5 | 484255 | 3690.19 | 655 | 643 | 131.1 |
| A | 13 | 210 | 44811 | 337.02 | 655 | 643 | 131.1 |
| B | 4 | 239 | 794331 | 5827.24 | 740 | 724 | 136.2 |
| B | 15 | 204 | 51634 | 373.82 | 740 | 724 | 136.2 |
| B | 11 | 51 | 41049 | 296.1 | 740 | 724 | 136.2 |
| C | 13 | 61 | 5421 | 27.82 | 745 | 749 | 168.0 |
| C | 8 | 128 | 4639 | 23.16 | 745 | 749 | 168.0 |
| C | 9 | 54 | 3905 | 18.79 | 745 | 749 | 168.0 |
| D | 10 | 253 | 434606 | 2545.0 | 726 | 708 | 170.5 |
| D | 11 | 129 | 421378 | 2467.41 | 726 | 708 | 170.5 |
| D | 8 | 195 | 239668 | 1401.6 | 726 | 708 | 170.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
