| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T02_9000001620_11105cztM0_level2.evt | modeM0/AS1G08_071T02_9000001620_11105cztM0_level2_quad_clean.evt |
| Size (bytes) | 733,734,720 | 95,535,360 |
| Size | 699.7 MB | 91.1 MB |
| Events in quadrant A | 6,678,396 | 571,699 |
| Events in quadrant B | 4,992,276 | 593,400 |
| Events in quadrant C | 4,021,428 | 597,100 |
| Events in quadrant D | 5,957,352 | 543,904 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 174 | 0 |
| B | 0 | 174 | 0 |
| C | 0 | 174 | 0 |
| D | 0 | 174 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25378 | 4 |
| B | 0 | 20065 | 3 |
| C | 0 | 17716 | 3 |
| D | 0 | 23238 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8440 | 928 | 10.995261% |
| B | 8440 | 551 | 6.528436% |
| C | 8440 | 268 | 3.175355% |
| D | 8440 | 763 | 9.040284% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9520 | 8441 | 427 | 427 | 4.49% | 5.06% |  |
| B | 9520 | 8442 | 125 | 125 | 1.31% | 1.48% |  |
| C | 9520 | 8443 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9520 | 8441 | 463 | 463 | 4.86% | 5.49% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 2531732 | 12010.15 | 1021 | 996 | 210.7 |
| A | 8 | 15 | 128955 | 607.26 | 1021 | 996 | 210.7 |
| A | 14 | 254 | 66462 | 310.68 | 1021 | 996 | 210.7 |
| B | 4 | 239 | 556037 | 2700.53 | 1049 | 1020 | 205.5 |
| B | 10 | 16 | 133915 | 646.62 | 1049 | 1020 | 205.5 |
| B | 15 | 204 | 81316 | 390.69 | 1049 | 1020 | 205.5 |
| C | 13 | 61 | 7958 | 28.85 | 1028 | 1031 | 240.1 |
| C | 8 | 128 | 5993 | 20.67 | 1028 | 1031 | 240.1 |
| C | 14 | 234 | 4619 | 14.94 | 1028 | 1031 | 240.1 |
| D | 10 | 253 | 1325931 | 5590.66 | 972 | 942 | 237.0 |
| D | 1 | 52 | 529098 | 2228.5 | 972 | 942 | 237.0 |
| D | 8 | 195 | 181918 | 763.61 | 972 | 942 | 237.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
