| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T02_9000001620_11111cztM0_level2.evt | modeM0/AS1G08_071T02_9000001620_11111cztM0_level2_quad_clean.evt |
| Size (bytes) | 569,108,160 | 84,772,800 |
| Size | 542.7 MB | 80.8 MB |
| Events in quadrant A | 4,831,191 | 522,681 |
| Events in quadrant B | 3,471,886 | 548,375 |
| Events in quadrant C | 2,952,354 | 542,696 |
| Events in quadrant D | 5,532,757 | 492,945 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18916 | 3 |
| B | 0 | 14650 | 2 |
| C | 0 | 13390 | 2 |
| D | 0 | 20854 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6596 | 364 | 5.518496% |
| B | 6596 | 80 | 1.212856% |
| C | 6596 | 11 | 0.166768% |
| D | 6596 | 710 | 10.764099% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7591 | 6597 | 235 | 235 | 3.10% | 3.56% |  |
| B | 7591 | 6597 | 25 | 25 | 0.33% | 0.38% |  |
| C | 7591 | 6597 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7591 | 6597 | 603 | 603 | 7.94% | 9.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1342641 | 8649.31 | 758 | 740 | 155.1 |
| A | 8 | 15 | 465122 | 2993.2 | 758 | 740 | 155.1 |
| A | 13 | 210 | 31580 | 198.78 | 758 | 740 | 155.1 |
| B | 4 | 239 | 195771 | 1309.94 | 780 | 761 | 148.9 |
| B | 10 | 16 | 83680 | 556.99 | 780 | 761 | 148.9 |
| B | 15 | 204 | 61690 | 409.28 | 780 | 761 | 148.9 |
| C | 13 | 61 | 5647 | 27.78 | 755 | 760 | 175.9 |
| C | 14 | 234 | 3493 | 15.54 | 755 | 760 | 175.9 |
| C | 12 | 4 | 2911 | 12.23 | 755 | 760 | 175.9 |
| D | 1 | 52 | 1320674 | 7564.59 | 715 | 694 | 174.5 |
| D | 10 | 253 | 1059145 | 6065.81 | 715 | 694 | 174.5 |
| D | 8 | 195 | 200541 | 1145.29 | 715 | 694 | 174.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
