| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_071T02_9000001620_11116cztM0_level2.evt | modeM0/AS1G08_071T02_9000001620_11116cztM0_level2_quad_clean.evt |
| Size (bytes) | 597,006,720 | 71,979,840 |
| Size | 569.3 MB | 68.6 MB |
| Events in quadrant A | 5,133,856 | 436,623 |
| Events in quadrant B | 4,062,687 | 447,146 |
| Events in quadrant C | 3,126,512 | 442,063 |
| Events in quadrant D | 5,316,333 | 398,777 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19611 | 3 |
| B | 0 | 16182 | 2 |
| C | 0 | 13379 | 2 |
| D | 0 | 20135 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6520 | 295 | 4.524540% |
| B | 6520 | 205 | 3.144172% |
| C | 6520 | 13 | 0.199387% |
| D | 6520 | 386 | 5.920245% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7850 | 6521 | 212 | 212 | 2.70% | 3.25% |  |
| B | 7850 | 6521 | 110 | 110 | 1.40% | 1.69% |  |
| C | 7850 | 6521 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7850 | 6521 | 303 | 303 | 3.86% | 4.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1874597 | 11427.49 | 816 | 802 | 164.0 |
| A | 14 | 254 | 73395 | 442.71 | 816 | 802 | 164.0 |
| A | 8 | 15 | 19320 | 112.93 | 816 | 802 | 164.0 |
| B | 4 | 239 | 610112 | 3881.69 | 832 | 815 | 157.0 |
| B | 3 | 189 | 44306 | 277.07 | 832 | 815 | 157.0 |
| B | 0 | 214 | 44001 | 275.13 | 832 | 815 | 157.0 |
| C | 13 | 61 | 5999 | 28.0 | 801 | 807 | 185.4 |
| C | 14 | 234 | 2833 | 10.92 | 801 | 807 | 185.4 |
| C | 3 | 202 | 1907 | 5.93 | 801 | 807 | 185.4 |
| D | 10 | 253 | 695986 | 3754.31 | 769 | 749 | 185.2 |
| D | 11 | 129 | 567185 | 3058.78 | 769 | 749 | 185.2 |
| D | 1 | 52 | 417231 | 2249.02 | 769 | 749 | 185.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
