| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_202T01_9000001640_11249cztM0_level2.evt | modeM0/AS1T01_202T01_9000001640_11249cztM0_level2_quad_clean.evt |
| Size (bytes) | 491,457,600 | 118,074,240 |
| Size | 468.7 MB | 112.6 MB |
| Events in quadrant A | 3,342,002 | 797,293 |
| Events in quadrant B | 4,013,854 | 778,559 |
| Events in quadrant C | 3,182,360 | 809,003 |
| Events in quadrant D | 3,910,604 | 744,513 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13958 | 2 |
| B | 0 | 16176 | 1 |
| C | 0 | 13777 | 1 |
| D | 0 | 15876 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6406 | 88 | 1.373712% |
| B | 6406 | 341 | 5.323135% |
| C | 6406 | 69 | 1.077115% |
| D | 6406 | 167 | 2.606931% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7036 | 6407 | 6 | 6 | 0.09% | 0.09% |  |
| B | 7036 | 6407 | 143 | 143 | 2.03% | 2.23% |  |
| C | 7036 | 6407 | 20 | 20 | 0.28% | 0.31% |  |
| D | 7036 | 6407 | 105 | 105 | 1.49% | 1.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 73384 | 410.98 | 790 | 774 | 176.7 |
| A | 14 | 238 | 52425 | 292.35 | 790 | 774 | 176.7 |
| A | 1 | 162 | 48533 | 270.32 | 790 | 774 | 176.7 |
| B | 4 | 239 | 748286 | 4748.01 | 781 | 765 | 157.4 |
| B | 11 | 51 | 91191 | 574.36 | 781 | 765 | 157.4 |
| B | 15 | 204 | 45151 | 281.93 | 781 | 765 | 157.4 |
| C | 4 | 254 | 172353 | 927.07 | 771 | 781 | 185.1 |
| C | 13 | 61 | 5743 | 26.81 | 771 | 781 | 185.1 |
| C | 14 | 234 | 2940 | 11.67 | 771 | 781 | 185.1 |
| D | 8 | 195 | 211245 | 1006.83 | 746 | 730 | 209.1 |
| D | 2 | 14 | 178245 | 849.0 | 746 | 730 | 209.1 |
| D | 13 | 104 | 173409 | 825.87 | 746 | 730 | 209.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
