| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C03_012T01_9000001642_11259cztM0_level2.evt | modeM0/AS1C03_012T01_9000001642_11259cztM0_level2_quad_clean.evt |
| Size (bytes) | 650,508,480 | 101,191,680 |
| Size | 620.4 MB | 96.5 MB |
| Events in quadrant A | 4,928,377 | 652,791 |
| Events in quadrant B | 4,516,247 | 677,814 |
| Events in quadrant C | 3,369,320 | 666,744 |
| Events in quadrant D | 6,433,155 | 599,450 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19294 | 3 |
| B | 0 | 17891 | 2 |
| C | 0 | 14291 | 2 |
| D | 0 | 23966 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6709 | 360 | 5.365926% |
| B | 6709 | 351 | 5.231778% |
| C | 6709 | 40 | 0.596214% |
| D | 6709 | 675 | 10.061112% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9104 | 6711 | 186 | 186 | 2.04% | 2.77% |  |
| B | 9104 | 6711 | 123 | 123 | 1.35% | 1.83% |  |
| C | 9104 | 6711 | 1 | 1 | 0.01% | 0.01% |  |
| D | 9104 | 6711 | 504 | 504 | 5.54% | 7.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 623645 | 3567.6 | 860 | 848 | 174.6 |
| A | 8 | 5 | 545750 | 3121.39 | 860 | 848 | 174.6 |
| A | 8 | 15 | 120924 | 687.84 | 860 | 848 | 174.6 |
| B | 4 | 239 | 878559 | 5419.91 | 868 | 849 | 161.9 |
| B | 11 | 51 | 119632 | 733.49 | 868 | 849 | 161.9 |
| B | 15 | 204 | 30741 | 184.58 | 868 | 849 | 161.9 |
| C | 9 | 204 | 22082 | 107.74 | 856 | 866 | 196.9 |
| C | 13 | 61 | 6281 | 27.5 | 856 | 866 | 196.9 |
| C | 12 | 4 | 5254 | 22.28 | 856 | 866 | 196.9 |
| D | 4 | 95 | 857587 | 4394.03 | 812 | 792 | 195.0 |
| D | 8 | 195 | 654659 | 3353.33 | 812 | 792 | 195.0 |
| D | 12 | 157 | 603667 | 3091.81 | 812 | 792 | 195.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
