| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_144T01_9000001652_11283cztM0_level2.evt | modeM0/AS1A04_144T01_9000001652_11283cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,079,867,520 | 120,228,480 |
| Size | 1.0 GB | 114.7 MB |
| Events in quadrant A | 10,814,491 | 720,569 |
| Events in quadrant B | 7,204,822 | 760,655 |
| Events in quadrant C | 4,485,811 | 756,234 |
| Events in quadrant D | 9,504,245 | 689,163 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 208 | 0 |
| B | 0 | 208 | 0 |
| C | 0 | 208 | 0 |
| D | 0 | 208 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 39073 | 2 |
| B | 0 | 28066 | 1 |
| C | 0 | 20768 | 1 |
| D | 0 | 35268 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10303 | 1732 | 16.810638% |
| B | 10303 | 756 | 7.337669% |
| C | 10303 | 39 | 0.378531% |
| D | 10303 | 1447 | 14.044453% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 10868 | 10301 | 1114 | 1114 | 10.25% | 10.81% |  |
| B | 10868 | 10303 | 445 | 445 | 4.09% | 4.32% |  |
| C | 10868 | 10303 | 0 | 0 | 0.00% | 0.00% |  |
| D | 10868 | 10302 | 864 | 864 | 7.95% | 8.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 4803583 | 21208.11 | 1108 | 1086 | 226.4 |
| A | 0 | 8 | 1250738 | 5518.54 | 1108 | 1086 | 226.4 |
| A | 14 | 238 | 168072 | 737.42 | 1108 | 1086 | 226.4 |
| B | 4 | 239 | 2400803 | 10711.97 | 1167 | 1139 | 224.0 |
| B | 11 | 51 | 141782 | 627.82 | 1167 | 1139 | 224.0 |
| B | 15 | 204 | 32289 | 139.05 | 1167 | 1139 | 224.0 |
| C | 13 | 61 | 8450 | 27.13 | 1150 | 1156 | 268.8 |
| C | 14 | 234 | 3536 | 8.85 | 1150 | 1156 | 268.8 |
| C | 3 | 202 | 2910 | 6.53 | 1150 | 1156 | 268.8 |
| D | 13 | 152 | 2011087 | 7713.08 | 1076 | 1043 | 260.6 |
| D | 10 | 253 | 877128 | 3361.77 | 1076 | 1043 | 260.6 |
| D | 12 | 157 | 856156 | 3281.3 | 1076 | 1043 | 260.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
