| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_144T01_9000001652_11302cztM0_level2.evt | modeM0/AS1A04_144T01_9000001652_11302cztM0_level2_quad_clean.evt |
| Size (bytes) | 610,269,120 | 91,517,760 |
| Size | 582.0 MB | 87.3 MB |
| Events in quadrant A | 4,598,491 | 594,866 |
| Events in quadrant B | 4,885,326 | 605,157 |
| Events in quadrant C | 3,073,362 | 607,005 |
| Events in quadrant D | 5,503,036 | 529,068 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17918 | 2 |
| B | 0 | 18752 | 1 |
| C | 0 | 13311 | 1 |
| D | 0 | 20609 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6235 | 458 | 7.345630% |
| B | 6235 | 690 | 11.066560% |
| C | 6235 | 39 | 0.625501% |
| D | 6235 | 546 | 8.757017% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7471 | 6236 | 307 | 307 | 4.11% | 4.92% |  |
| B | 7471 | 6236 | 373 | 373 | 4.99% | 5.98% |  |
| C | 7471 | 6236 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7471 | 6236 | 458 | 458 | 6.13% | 7.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1547316 | 10009.8 | 766 | 752 | 154.5 |
| A | 0 | 8 | 56845 | 363.05 | 766 | 752 | 154.5 |
| A | 8 | 15 | 13001 | 79.28 | 766 | 752 | 154.5 |
| B | 4 | 239 | 1626036 | 10957.07 | 774 | 757 | 148.3 |
| B | 4 | 81 | 140374 | 941.25 | 774 | 757 | 148.3 |
| B | 3 | 189 | 46412 | 307.79 | 774 | 757 | 148.3 |
| C | 14 | 234 | 10444 | 53.15 | 785 | 792 | 181.6 |
| C | 13 | 61 | 5831 | 27.75 | 785 | 792 | 181.6 |
| C | 9 | 204 | 1966 | 6.47 | 785 | 792 | 181.6 |
| D | 7 | 80 | 983557 | 5499.78 | 746 | 726 | 178.7 |
| D | 10 | 253 | 740654 | 4140.53 | 746 | 726 | 178.7 |
| D | 8 | 195 | 621536 | 3473.96 | 746 | 726 | 178.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
