| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_062T01_9000001660_11357cztM0_level2.evt | modeM0/AS1G08_062T01_9000001660_11357cztM0_level2_quad_clean.evt |
| Size (bytes) | 492,678,720 | 91,071,360 |
| Size | 469.9 MB | 86.9 MB |
| Events in quadrant A | 3,004,072 | 601,876 |
| Events in quadrant B | 4,320,914 | 578,923 |
| Events in quadrant C | 2,789,393 | 594,732 |
| Events in quadrant D | 4,381,527 | 545,501 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12993 | 2 |
| B | 0 | 17018 | 1 |
| C | 0 | 12716 | 1 |
| D | 0 | 17263 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6260 | 60 | 0.958466% |
| B | 6260 | 406 | 6.485623% |
| C | 6260 | 34 | 0.543131% |
| D | 6260 | 483 | 7.715655% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7230 | 6261 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7230 | 6261 | 240 | 240 | 3.32% | 3.83% |  |
| C | 7230 | 6261 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7230 | 6261 | 319 | 319 | 4.41% | 5.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 37300 | 241.3 | 740 | 723 | 151.6 |
| A | 15 | 174 | 30213 | 194.54 | 740 | 723 | 151.6 |
| A | 1 | 178 | 21966 | 140.14 | 740 | 723 | 151.6 |
| B | 4 | 239 | 852904 | 6198.99 | 717 | 699 | 137.5 |
| B | 3 | 64 | 502742 | 3651.89 | 717 | 699 | 137.5 |
| B | 15 | 204 | 48392 | 346.92 | 717 | 699 | 137.5 |
| C | 13 | 61 | 5361 | 27.9 | 714 | 717 | 166.5 |
| C | 8 | 222 | 2788 | 12.44 | 714 | 717 | 166.5 |
| C | 3 | 202 | 1816 | 6.6 | 714 | 717 | 166.5 |
| D | 10 | 253 | 1094157 | 6664.66 | 687 | 668 | 164.1 |
| D | 13 | 104 | 142226 | 862.78 | 687 | 668 | 164.1 |
| D | 2 | 120 | 122515 | 742.64 | 687 | 668 | 164.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
