| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_022T03_9000001664_11386cztM0_level2.evt | modeM0/AS1A04_022T03_9000001664_11386cztM0_level2_quad_clean.evt |
| Size (bytes) | 643,792,320 | 95,688,000 |
| Size | 614.0 MB | 91.3 MB |
| Events in quadrant A | 4,457,896 | 583,537 |
| Events in quadrant B | 4,620,318 | 586,429 |
| Events in quadrant C | 3,516,758 | 635,249 |
| Events in quadrant D | 6,389,121 | 565,137 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18017 | 3 |
| B | 0 | 18420 | 2 |
| C | 0 | 15501 | 2 |
| D | 0 | 24026 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7573 | 319 | 4.212333% |
| B | 7573 | 360 | 4.753730% |
| C | 7573 | 90 | 1.188433% |
| D | 7573 | 779 | 10.286544% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9383 | 7575 | 109 | 109 | 1.16% | 1.44% |  |
| B | 9383 | 7575 | 147 | 147 | 1.57% | 1.94% |  |
| C | 9383 | 7575 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9383 | 7575 | 529 | 529 | 5.64% | 6.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 883746 | 4735.79 | 908 | 885 | 186.4 |
| A | 1 | 162 | 25565 | 132.38 | 908 | 885 | 186.4 |
| A | 1 | 178 | 15235 | 76.97 | 908 | 885 | 186.4 |
| B | 4 | 239 | 895773 | 5115.73 | 906 | 883 | 174.9 |
| B | 11 | 51 | 114459 | 649.27 | 906 | 883 | 174.9 |
| B | 15 | 204 | 25749 | 142.15 | 906 | 883 | 174.9 |
| C | 13 | 61 | 6471 | 26.5 | 900 | 903 | 210.1 |
| C | 14 | 67 | 3162 | 10.75 | 900 | 903 | 210.1 |
| C | 3 | 202 | 2205 | 6.2 | 900 | 903 | 210.1 |
| D | 1 | 52 | 1242124 | 6054.7 | 859 | 834 | 205.0 |
| D | 2 | 14 | 625265 | 3045.82 | 859 | 834 | 205.0 |
| D | 10 | 253 | 601416 | 2929.49 | 859 | 834 | 205.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
