| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_054T02_9000001674_11436cztM0_level2.evt | modeM0/AS1A04_054T02_9000001674_11436cztM0_level2_quad_clean.evt |
| Size (bytes) | 267,868,800 | 41,198,400 |
| Size | 255.5 MB | 39.3 MB |
| Events in quadrant A | 1,839,771 | 254,698 |
| Events in quadrant B | 2,249,643 | 254,106 |
| Events in quadrant C | 1,729,967 | 243,806 |
| Events in quadrant D | 2,045,427 | 238,241 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7759 | 2 |
| B | 0 | 8970 | 1 |
| C | 0 | 7605 | 1 |
| D | 0 | 8460 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 74 | 0 |
| B | 0 | 74 | 0 |
| C | 0 | 74 | 0 |
| D | 0 | 74 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3621 | 76 | 2.098868% |
| B | 3621 | 185 | 5.109086% |
| C | 3621 | 43 | 1.187517% |
| D | 3621 | 78 | 2.154101% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4726 | 3622 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4726 | 3622 | 52 | 52 | 1.10% | 1.44% |  |
| C | 4726 | 3622 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4726 | 3622 | 39 | 39 | 0.83% | 1.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 22890 | 237.77 | 458 | 450 | 94.4 |
| A | 1 | 178 | 12620 | 128.95 | 458 | 450 | 94.4 |
| A | 1 | 161 | 10854 | 110.24 | 458 | 450 | 94.4 |
| B | 4 | 239 | 384320 | 4339.72 | 453 | 441 | 88.5 |
| B | 3 | 189 | 47785 | 535.22 | 453 | 441 | 88.5 |
| B | 15 | 204 | 30846 | 343.73 | 453 | 441 | 88.5 |
| C | 13 | 61 | 3210 | 26.34 | 443 | 444 | 105.0 |
| C | 5 | 33 | 1289 | 8.04 | 443 | 444 | 105.0 |
| C | 14 | 234 | 1112 | 6.36 | 443 | 444 | 105.0 |
| D | 1 | 52 | 133325 | 1249.22 | 437 | 423 | 106.4 |
| D | 10 | 253 | 116747 | 1093.39 | 437 | 423 | 106.4 |
| D | 13 | 152 | 78419 | 733.13 | 437 | 423 | 106.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
