| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_021T03_9000001678_11451cztM0_level2.evt | modeM0/AS1A04_021T03_9000001678_11451cztM0_level2_quad_clean.evt |
| Size (bytes) | 530,619,840 | 93,810,240 |
| Size | 506.0 MB | 89.5 MB |
| Events in quadrant A | 3,365,716 | 590,283 |
| Events in quadrant B | 4,909,271 | 568,567 |
| Events in quadrant C | 3,126,831 | 631,103 |
| Events in quadrant D | 4,218,160 | 588,598 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14342 | 3 |
| B | 0 | 18939 | 2 |
| C | 0 | 13728 | 2 |
| D | 0 | 17014 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6632 | 81 | 1.221351% |
| B | 6632 | 479 | 7.222557% |
| C | 6632 | 51 | 0.768999% |
| D | 6632 | 251 | 3.784680% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7603 | 6634 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7603 | 6634 | 243 | 243 | 3.20% | 3.66% |  |
| C | 7603 | 6634 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7603 | 6634 | 145 | 145 | 1.91% | 2.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 66372 | 402.46 | 806 | 791 | 163.0 |
| A | 8 | 5 | 43016 | 259.13 | 806 | 791 | 163.0 |
| A | 1 | 178 | 39493 | 237.51 | 806 | 791 | 163.0 |
| B | 4 | 239 | 1498659 | 10050.04 | 787 | 767 | 149.0 |
| B | 11 | 51 | 130755 | 872.15 | 787 | 767 | 149.0 |
| B | 15 | 204 | 76807 | 510.19 | 787 | 767 | 149.0 |
| C | 13 | 61 | 5762 | 26.55 | 802 | 808 | 186.6 |
| C | 14 | 234 | 2597 | 9.59 | 802 | 808 | 186.6 |
| C | 3 | 202 | 1975 | 6.25 | 802 | 808 | 186.6 |
| D | 13 | 249 | 586686 | 3128.62 | 785 | 765 | 187.3 |
| D | 10 | 253 | 149383 | 793.57 | 785 | 765 | 187.3 |
| D | 13 | 104 | 116444 | 617.69 | 785 | 765 | 187.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
