| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_107T01_9000001684_11489cztM0_level2.evt | modeM0/AS1A04_107T01_9000001684_11489cztM0_level2_quad_clean.evt |
| Size (bytes) | 589,743,360 | 87,266,880 |
| Size | 562.4 MB | 83.2 MB |
| Events in quadrant A | 6,733,111 | 518,891 |
| Events in quadrant B | 3,994,788 | 562,875 |
| Events in quadrant C | 3,011,430 | 563,020 |
| Events in quadrant D | 3,675,822 | 539,496 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24496 | 3 |
| B | 0 | 16053 | 2 |
| C | 0 | 13442 | 2 |
| D | 0 | 15215 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6573 | 1208 | 18.378214% |
| B | 6573 | 209 | 3.179674% |
| C | 6573 | 47 | 0.715046% |
| D | 6573 | 166 | 2.525483% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7639 | 6574 | 754 | 754 | 9.87% | 11.47% |  |
| B | 7639 | 6575 | 67 | 67 | 0.88% | 1.02% |  |
| C | 7639 | 6575 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7639 | 6575 | 87 | 87 | 1.14% | 1.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 3594697 | 24024.1 | 747 | 734 | 149.6 |
| A | 15 | 223 | 54362 | 358.48 | 747 | 734 | 149.6 |
| A | 1 | 162 | 35556 | 232.77 | 747 | 734 | 149.6 |
| B | 4 | 239 | 595183 | 3933.44 | 793 | 774 | 151.1 |
| B | 11 | 51 | 152094 | 1001.34 | 793 | 774 | 151.1 |
| B | 15 | 204 | 86914 | 570.02 | 793 | 774 | 151.1 |
| C | 12 | 4 | 7524 | 37.88 | 770 | 776 | 178.2 |
| C | 13 | 61 | 5765 | 28.0 | 770 | 776 | 178.2 |
| C | 3 | 202 | 1807 | 5.79 | 770 | 776 | 178.2 |
| D | 1 | 52 | 470307 | 2508.75 | 771 | 750 | 187.2 |
| D | 2 | 120 | 122096 | 648.33 | 771 | 750 | 187.2 |
| D | 13 | 152 | 47607 | 250.35 | 771 | 750 | 187.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
