| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_107T01_9000001684_11496cztM0_level2.evt | modeM0/AS1A04_107T01_9000001684_11496cztM0_level2_quad_clean.evt |
| Size (bytes) | 647,876,160 | 92,560,320 |
| Size | 617.9 MB | 88.3 MB |
| Events in quadrant A | 6,429,381 | 566,483 |
| Events in quadrant B | 5,586,449 | 581,397 |
| Events in quadrant C | 3,044,088 | 602,833 |
| Events in quadrant D | 4,101,268 | 578,147 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23762 | 2 |
| B | 0 | 21132 | 2 |
| C | 0 | 13860 | 2 |
| D | 0 | 16638 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6793 | 689 | 10.142794% |
| B | 6793 | 576 | 8.479317% |
| C | 6793 | 17 | 0.250258% |
| D | 6793 | 69 | 1.015752% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7574 | 6794 | 451 | 451 | 5.95% | 6.64% |  |
| B | 7574 | 6795 | 380 | 380 | 5.02% | 5.59% |  |
| C | 7574 | 6794 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7574 | 6794 | 30 | 30 | 0.40% | 0.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 3269089 | 20945.9 | 770 | 756 | 156.0 |
| A | 9 | 143 | 32614 | 204.17 | 770 | 756 | 156.0 |
| A | 3 | 1 | 31855 | 199.31 | 770 | 756 | 156.0 |
| B | 4 | 81 | 1253419 | 8454.17 | 775 | 757 | 148.2 |
| B | 4 | 239 | 952877 | 6425.82 | 775 | 757 | 148.2 |
| B | 11 | 51 | 190316 | 1279.33 | 775 | 757 | 148.2 |
| C | 13 | 61 | 5821 | 27.73 | 781 | 785 | 181.6 |
| C | 3 | 202 | 1856 | 5.9 | 781 | 785 | 181.6 |
| C | -1 | -1 | -1 | -1.0 | 781 | 785 | 181.6 |
| D | 13 | 152 | 299167 | 1603.24 | 781 | 762 | 186.1 |
| D | 10 | 157 | 297194 | 1592.64 | 781 | 762 | 186.1 |
| D | 1 | 52 | 147581 | 788.82 | 781 | 762 | 186.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
