| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_009T01_9000001692_11549cztM0_level2.evt | modeM0/AS1G08_009T01_9000001692_11549cztM0_level2_quad_clean.evt |
| Size (bytes) | 684,227,520 | 73,592,640 |
| Size | 652.5 MB | 70.2 MB |
| Events in quadrant A | 5,472,749 | 457,288 |
| Events in quadrant B | 5,042,964 | 448,139 |
| Events in quadrant C | 3,338,179 | 449,891 |
| Events in quadrant D | 6,425,391 | 416,167 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21040 | 3 |
| B | 0 | 19337 | 2 |
| C | 0 | 13850 | 2 |
| D | 0 | 23392 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6544 | 362 | 5.531785% |
| B | 6544 | 521 | 7.961491% |
| C | 6544 | 62 | 0.947433% |
| D | 6544 | 1290 | 19.712714% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7805 | 6546 | 135 | 135 | 1.73% | 2.06% |  |
| B | 7805 | 6546 | 276 | 276 | 3.54% | 4.22% |  |
| C | 7805 | 6546 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7805 | 6546 | 952 | 952 | 12.20% | 14.54% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1613890 | 9175.33 | 875 | 861 | 175.8 |
| A | 1 | 162 | 160491 | 908.02 | 875 | 861 | 175.8 |
| A | 1 | 178 | 94448 | 532.35 | 875 | 861 | 175.8 |
| B | 4 | 239 | 962892 | 5975.36 | 859 | 844 | 161.0 |
| B | 3 | 64 | 484085 | 3001.45 | 859 | 844 | 161.0 |
| B | 11 | 51 | 126393 | 779.8 | 859 | 844 | 161.0 |
| C | 13 | 61 | 6252 | 27.66 | 854 | 863 | 194.8 |
| C | 7 | 159 | 5071 | 21.6 | 854 | 863 | 194.8 |
| C | 13 | 250 | 2751 | 9.69 | 854 | 863 | 194.8 |
| D | 13 | 137 | 2795163 | 14512.79 | 799 | 781 | 192.5 |
| D | 1 | 52 | 305586 | 1583.02 | 799 | 781 | 192.5 |
| D | 2 | 120 | 149730 | 773.58 | 799 | 781 | 192.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
