| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_137T01_9000001700_11576cztM0_level2.evt | modeM0/AS1A04_137T01_9000001700_11576cztM0_level2_quad_clean.evt |
| Size (bytes) | 569,983,680 | 72,699,840 |
| Size | 543.6 MB | 69.3 MB |
| Events in quadrant A | 4,627,959 | 425,592 |
| Events in quadrant B | 4,753,425 | 418,458 |
| Events in quadrant C | 3,318,468 | 444,443 |
| Events in quadrant D | 4,085,851 | 423,126 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18398 | 3 |
| B | 0 | 18628 | 2 |
| C | 0 | 14451 | 2 |
| D | 0 | 16696 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7021 | 284 | 4.045008% |
| B | 7021 | 401 | 5.711437% |
| C | 7021 | 31 | 0.441533% |
| D | 7021 | 121 | 1.723401% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9077 | 7024 | 131 | 131 | 1.44% | 1.87% |  |
| B | 9077 | 7024 | 218 | 218 | 2.40% | 3.10% |  |
| C | 9077 | 7024 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9077 | 7024 | 79 | 79 | 0.87% | 1.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1169751 | 6660.35 | 860 | 842 | 175.5 |
| A | 1 | 162 | 44740 | 250.13 | 860 | 842 | 175.5 |
| A | 1 | 178 | 26326 | 145.21 | 860 | 842 | 175.5 |
| B | 4 | 239 | 606918 | 3698.08 | 861 | 842 | 163.9 |
| B | 15 | 255 | 476953 | 2905.07 | 861 | 842 | 163.9 |
| B | 3 | 64 | 166153 | 1008.67 | 861 | 842 | 163.9 |
| C | 13 | 61 | 6236 | 27.31 | 850 | 856 | 197.0 |
| C | 12 | 4 | 2344 | 7.55 | 850 | 856 | 197.0 |
| C | 3 | 202 | 2016 | 5.89 | 850 | 856 | 197.0 |
| D | 10 | 253 | 348533 | 1739.36 | 839 | 815 | 199.9 |
| D | 5 | 222 | 216174 | 1077.27 | 839 | 815 | 199.9 |
| D | 13 | 152 | 172521 | 858.91 | 839 | 815 | 199.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
