| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_137T01_9000001700_11578cztM0_level2.evt | modeM0/AS1A04_137T01_9000001700_11578cztM0_level2_quad_clean.evt |
| Size (bytes) | 556,894,080 | 77,235,840 |
| Size | 531.1 MB | 73.7 MB |
| Events in quadrant A | 4,757,311 | 474,503 |
| Events in quadrant B | 4,976,130 | 465,452 |
| Events in quadrant C | 3,203,762 | 487,663 |
| Events in quadrant D | 3,495,732 | 465,394 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18507 | 3 |
| B | 0 | 18904 | 2 |
| C | 0 | 13451 | 2 |
| D | 0 | 14301 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6384 | 282 | 4.417293% |
| B | 6384 | 515 | 8.067043% |
| C | 6384 | 62 | 0.971178% |
| D | 6384 | 121 | 1.895363% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7620 | 6386 | 100 | 100 | 1.31% | 1.57% |  |
| B | 7620 | 6386 | 272 | 272 | 3.57% | 4.26% |  |
| C | 7620 | 6386 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7620 | 6386 | 38 | 38 | 0.50% | 0.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1329680 | 7804.51 | 846 | 829 | 170.3 |
| A | 1 | 162 | 55328 | 320.08 | 846 | 829 | 170.3 |
| A | 1 | 178 | 30065 | 171.71 | 846 | 829 | 170.3 |
| B | 4 | 239 | 915912 | 5762.57 | 838 | 820 | 158.8 |
| B | 15 | 255 | 417728 | 2625.38 | 838 | 820 | 158.8 |
| B | 15 | 204 | 175492 | 1099.96 | 838 | 820 | 158.8 |
| C | 12 | 4 | 7798 | 36.99 | 820 | 827 | 188.4 |
| C | 13 | 61 | 6077 | 27.86 | 820 | 827 | 188.4 |
| C | 3 | 202 | 1970 | 6.07 | 820 | 827 | 188.4 |
| D | 5 | 222 | 125231 | 640.43 | 816 | 795 | 194.3 |
| D | 13 | 122 | 82927 | 422.71 | 816 | 795 | 194.3 |
| D | 10 | 253 | 71495 | 363.87 | 816 | 795 | 194.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
