| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_198T01_9000001708_11616cztM0_level2.evt | modeM0/AS1A04_198T01_9000001708_11616cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,043,225,280 | 160,289,280 |
| Size | 994.9 MB | 152.9 MB |
| Events in quadrant A | 11,279,655 | 960,548 |
| Events in quadrant B | 6,999,838 | 1,031,725 |
| Events in quadrant C | 5,579,375 | 1,011,547 |
| Events in quadrant D | 6,873,745 | 969,023 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 258 | 0 |
| B | 0 | 258 | 0 |
| C | 0 | 258 | 0 |
| D | 0 | 258 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42251 | 4 |
| B | 0 | 29480 | 3 |
| C | 0 | 25723 | 3 |
| D | 0 | 29772 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12752 | 1364 | 10.696361% |
| B | 12752 | 275 | 2.156524% |
| C | 12752 | 14 | 0.109787% |
| D | 12752 | 241 | 1.889900% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14149 | 12755 | 890 | 890 | 6.29% | 6.98% |  |
| B | 14149 | 12755 | 112 | 112 | 0.79% | 0.88% |  |
| C | 14149 | 12755 | 0 | 0 | 0.00% | 0.00% |  |
| D | 14149 | 12755 | 155 | 155 | 1.10% | 1.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 5019991 | 17539.72 | 1408 | 1376 | 286.1 |
| A | 1 | 162 | 290677 | 1011.09 | 1408 | 1376 | 286.1 |
| A | 1 | 178 | 167598 | 580.93 | 1408 | 1376 | 286.1 |
| B | 4 | 239 | 1032794 | 3671.49 | 1469 | 1433 | 280.9 |
| B | 10 | 16 | 80622 | 281.9 | 1469 | 1433 | 280.9 |
| B | 11 | 51 | 43301 | 149.04 | 1469 | 1433 | 280.9 |
| C | 13 | 61 | 10620 | 27.69 | 1429 | 1435 | 331.7 |
| C | 14 | 234 | 6406 | 14.99 | 1429 | 1435 | 331.7 |
| C | 8 | 222 | 3622 | 6.59 | 1429 | 1435 | 331.7 |
| D | 1 | 52 | 661936 | 1962.7 | 1406 | 1368 | 336.6 |
| D | 10 | 253 | 450775 | 1335.29 | 1406 | 1368 | 336.6 |
| D | 10 | 199 | 131593 | 386.93 | 1406 | 1368 | 336.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
