| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_198T01_9000001708_11621cztM0_level2.evt | modeM0/AS1A04_198T01_9000001708_11621cztM0_level2_quad_clean.evt |
| Size (bytes) | 597,827,520 | 71,199,360 |
| Size | 570.1 MB | 67.9 MB |
| Events in quadrant A | 4,275,386 | 458,286 |
| Events in quadrant B | 3,457,249 | 473,719 |
| Events in quadrant C | 2,932,157 | 465,529 |
| Events in quadrant D | 7,034,060 | 338,583 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16724 | 2 |
| B | 0 | 13961 | 1 |
| C | 0 | 12496 | 1 |
| D | 0 | 24858 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5991 | 208 | 3.471874% |
| B | 5991 | 99 | 1.652479% |
| C | 5991 | 33 | 0.550826% |
| D | 5991 | 1884 | 31.447171% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7212 | 5993 | 87 | 87 | 1.21% | 1.45% |  |
| B | 7212 | 5993 | 35 | 35 | 0.49% | 0.58% |  |
| C | 7212 | 5993 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7212 | 5993 | 1686 | 1686 | 23.38% | 28.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1063954 | 6977.33 | 752 | 738 | 152.4 |
| A | 1 | 162 | 117934 | 769.1 | 752 | 738 | 152.4 |
| A | 1 | 178 | 67135 | 435.73 | 752 | 738 | 152.4 |
| B | 4 | 239 | 221910 | 1544.37 | 760 | 741 | 143.2 |
| B | 3 | 64 | 162764 | 1131.37 | 760 | 741 | 143.2 |
| B | 11 | 51 | 66133 | 456.62 | 760 | 741 | 143.2 |
| C | 13 | 61 | 5645 | 28.39 | 749 | 754 | 172.3 |
| C | 8 | 128 | 4903 | 24.08 | 749 | 754 | 172.3 |
| C | 8 | 112 | 2239 | 8.62 | 749 | 754 | 172.3 |
| D | 13 | 122 | 4333564 | 29413.16 | 622 | 605 | 147.3 |
| D | 1 | 52 | 130746 | 883.43 | 622 | 605 | 147.3 |
| D | 13 | 152 | 67302 | 452.76 | 622 | 605 | 147.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
