| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_049T01_9000001710_11635cztM0_level2.evt | modeM0/AS1A04_049T01_9000001710_11635cztM0_level2_quad_clean.evt |
| Size (bytes) | 875,295,360 | 55,592,640 |
| Size | 834.7 MB | 53.0 MB |
| Events in quadrant A | 4,930,364 | 356,874 |
| Events in quadrant B | 3,638,976 | 370,352 |
| Events in quadrant C | 2,859,361 | 375,978 |
| Events in quadrant D | 14,665,550 | 150,156 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18851 | 2 |
| B | 0 | 14661 | 1 |
| C | 0 | 12521 | 1 |
| D | 0 | 47741 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6138 | 377 | 6.142066% |
| B | 6138 | 152 | 2.476377% |
| C | 6138 | 20 | 0.325839% |
| D | 6138 | 5209 | 84.864777% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7359 | 6141 | 233 | 233 | 3.17% | 3.79% |  |
| B | 7359 | 6141 | 66 | 66 | 0.90% | 1.07% |  |
| C | 7359 | 6141 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7359 | 6136 | 4686 | 4686 | 63.68% | 76.37% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 1596525 | 10554.78 | 741 | 724 | 151.2 |
| A | 1 | 162 | 136220 | 896.18 | 741 | 724 | 151.2 |
| A | 9 | 143 | 130753 | 860.02 | 741 | 724 | 151.2 |
| B | 4 | 239 | 547930 | 3857.12 | 755 | 738 | 141.9 |
| B | 15 | 204 | 57476 | 399.94 | 755 | 738 | 141.9 |
| B | 15 | 255 | 32816 | 226.12 | 755 | 738 | 141.9 |
| C | 13 | 61 | 5376 | 27.34 | 732 | 736 | 169.7 |
| C | 12 | 4 | 2924 | 12.89 | 732 | 736 | 169.7 |
| C | 3 | 202 | 1901 | 6.86 | 732 | 736 | 169.7 |
| D | 1 | 52 | 12680655 | 151923.97 | 343 | 333 | 83.5 |
| D | 13 | 152 | 489331 | 5858.72 | 343 | 333 | 83.5 |
| D | 13 | 104 | 55195 | 657.31 | 343 | 333 | 83.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
