| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_026T01_9000001712_11636cztM0_level2.evt | modeM0/AS1A04_026T01_9000001712_11636cztM0_level2_quad_clean.evt |
| Size (bytes) | 311,140,800 | 63,852,480 |
| Size | 296.7 MB | 60.9 MB |
| Events in quadrant A | 2,771,870 | 428,091 |
| Events in quadrant B | 1,896,580 | 454,403 |
| Events in quadrant C | 1,564,024 | 430,103 |
| Events in quadrant D | 2,969,496 | 390,654 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 68 | 0 |
| B | 0 | 68 | 0 |
| C | 0 | 68 | 0 |
| D | 0 | 68 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10488 | 2 |
| B | 0 | 7549 | 1 |
| C | 0 | 6604 | 1 |
| D | 0 | 11095 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3235 | 290 | 8.964451% |
| B | 3235 | 58 | 1.792890% |
| C | 3235 | 5 | 0.154560% |
| D | 3235 | 310 | 9.582689% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4526 | 3236 | 157 | 157 | 3.47% | 4.85% |  |
| B | 4526 | 3236 | 15 | 15 | 0.33% | 0.46% |  |
| C | 4526 | 3236 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4526 | 3237 | 237 | 237 | 5.24% | 7.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 970704 | 11718.07 | 405 | 397 | 82.8 |
| A | 1 | 162 | 85653 | 1029.61 | 405 | 397 | 82.8 |
| A | 1 | 178 | 49773 | 596.3 | 405 | 397 | 82.8 |
| B | 4 | 239 | 203331 | 2569.59 | 417 | 408 | 79.0 |
| B | 0 | 219 | 35428 | 443.45 | 417 | 408 | 79.0 |
| B | 15 | 204 | 30626 | 382.65 | 417 | 408 | 79.0 |
| C | 12 | 4 | 4136 | 40.29 | 399 | 401 | 92.7 |
| C | 13 | 61 | 2906 | 27.02 | 399 | 401 | 92.7 |
| C | 4 | 175 | 1023 | 6.71 | 399 | 401 | 92.7 |
| D | 13 | 152 | 826377 | 8872.67 | 381 | 369 | 93.1 |
| D | 10 | 253 | 386963 | 4152.65 | 381 | 369 | 93.1 |
| D | 1 | 52 | 120211 | 1287.3 | 381 | 369 | 93.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
