| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_026T04_9000001714_11642cztM0_level2.evt | modeM0/AS1A04_026T04_9000001714_11642cztM0_level2_quad_clean.evt |
| Size (bytes) | 624,528,000 | 138,335,040 |
| Size | 595.6 MB | 131.9 MB |
| Events in quadrant A | 4,716,819 | 943,752 |
| Events in quadrant B | 4,978,398 | 933,700 |
| Events in quadrant C | 3,421,723 | 914,845 |
| Events in quadrant D | 5,277,897 | 864,460 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 4 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19352 | 3 |
| B | 0 | 19970 | 2 |
| C | 0 | 15617 | 2 |
| D | 0 | 20971 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7659 | 149 | 1.945424% |
| B | 7659 | 440 | 5.744875% |
| C | 7659 | 24 | 0.313357% |
| D | 7659 | 402 | 5.248727% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7985 | 7661 | 8 | 8 | 0.10% | 0.10% |  |
| B | 7985 | 7661 | 208 | 208 | 2.60% | 2.72% |  |
| C | 7985 | 7661 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7985 | 7661 | 263 | 263 | 3.29% | 3.43% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 351202 | 1883.01 | 902 | 880 | 186.0 |
| A | 8 | 5 | 239802 | 1284.23 | 902 | 880 | 186.0 |
| A | 1 | 178 | 220305 | 1179.43 | 902 | 880 | 186.0 |
| B | 4 | 239 | 1267282 | 7454.96 | 886 | 862 | 169.9 |
| B | 15 | 204 | 116298 | 679.53 | 886 | 862 | 169.9 |
| B | 0 | 219 | 68751 | 399.64 | 886 | 862 | 169.9 |
| C | 8 | 128 | 9684 | 43.66 | 870 | 869 | 201.9 |
| C | 13 | 61 | 6417 | 27.48 | 870 | 869 | 201.9 |
| C | 8 | 112 | 6144 | 26.13 | 870 | 869 | 201.9 |
| D | 10 | 253 | 364630 | 1769.31 | 856 | 831 | 205.6 |
| D | 13 | 137 | 308461 | 1496.13 | 856 | 831 | 205.6 |
| D | 7 | 80 | 301524 | 1462.4 | 856 | 831 | 205.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
