| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_037T01_9000001716_11647cztM0_level2.evt | modeM0/AS1A04_037T01_9000001716_11647cztM0_level2_quad_clean.evt |
| Size (bytes) | 524,232,000 | 96,379,200 |
| Size | 499.9 MB | 91.9 MB |
| Events in quadrant A | 4,052,256 | 616,747 |
| Events in quadrant B | 3,639,447 | 625,888 |
| Events in quadrant C | 3,201,967 | 615,262 |
| Events in quadrant D | 4,516,912 | 582,485 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16546 | 3 |
| B | 0 | 15155 | 2 |
| C | 0 | 14027 | 2 |
| D | 0 | 18081 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6869 | 76 | 1.106420% |
| B | 6869 | 169 | 2.460329% |
| C | 6869 | 37 | 0.538652% |
| D | 6869 | 333 | 4.847867% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8870 | 6872 | 17 | 17 | 0.19% | 0.25% |  |
| B | 8870 | 6872 | 70 | 70 | 0.79% | 1.02% |  |
| C | 8870 | 6872 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8870 | 6872 | 221 | 221 | 2.49% | 3.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 247224 | 1457.58 | 827 | 810 | 169.1 |
| A | 1 | 162 | 209897 | 1236.78 | 827 | 810 | 169.1 |
| A | 1 | 178 | 126740 | 744.9 | 827 | 810 | 169.1 |
| B | 4 | 239 | 337270 | 2125.64 | 832 | 812 | 158.3 |
| B | 15 | 204 | 45263 | 280.83 | 832 | 812 | 158.3 |
| B | 12 | 111 | 18657 | 112.74 | 832 | 812 | 158.3 |
| C | 15 | 208 | 8615 | 41.0 | 817 | 819 | 190.2 |
| C | 12 | 4 | 6237 | 28.49 | 817 | 819 | 190.2 |
| C | 13 | 61 | 5879 | 26.61 | 817 | 819 | 190.2 |
| D | 4 | 95 | 696512 | 3679.64 | 790 | 768 | 189.1 |
| D | 1 | 52 | 476875 | 2518.02 | 790 | 768 | 189.1 |
| D | 10 | 199 | 146507 | 770.78 | 790 | 768 | 189.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
