| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_037T02_9000001718_11661cztM0_level2.evt | modeM0/AS1A04_037T02_9000001718_11661cztM0_level2_quad_clean.evt |
| Size (bytes) | 514,105,920 | 81,823,680 |
| Size | 490.3 MB | 78.0 MB |
| Events in quadrant A | 6,181,682 | 496,822 |
| Events in quadrant B | 3,079,967 | 530,461 |
| Events in quadrant C | 2,867,344 | 516,051 |
| Events in quadrant D | 3,015,395 | 496,602 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22795 | 2 |
| B | 0 | 13116 | 2 |
| C | 0 | 12684 | 2 |
| D | 0 | 13176 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6267 | 660 | 10.531355% |
| B | 6267 | 35 | 0.558481% |
| C | 6267 | 8 | 0.127653% |
| D | 6267 | 20 | 0.319132% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8218 | 6269 | 439 | 439 | 5.34% | 7.00% |  |
| B | 8218 | 6270 | 6 | 6 | 0.07% | 0.10% |  |
| C | 8218 | 6270 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8218 | 6270 | 10 | 10 | 0.12% | 0.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 5 | 3000062 | 20460.89 | 719 | 706 | 146.6 |
| A | 1 | 162 | 148050 | 1005.15 | 719 | 706 | 146.6 |
| A | 1 | 178 | 87745 | 593.76 | 719 | 706 | 146.6 |
| B | 4 | 239 | 76832 | 526.07 | 750 | 731 | 144.7 |
| B | 15 | 204 | 35362 | 239.4 | 750 | 731 | 144.7 |
| B | 12 | 111 | 17340 | 114.82 | 750 | 731 | 144.7 |
| C | 8 | 128 | 8826 | 47.29 | 732 | 737 | 171.1 |
| C | 13 | 61 | 5167 | 25.9 | 732 | 737 | 171.1 |
| C | 8 | 112 | 4483 | 21.9 | 732 | 737 | 171.1 |
| D | 2 | 136 | 91085 | 522.67 | 721 | 701 | 172.9 |
| D | 13 | 104 | 67979 | 389.06 | 721 | 701 | 172.9 |
| D | 8 | 195 | 46845 | 266.84 | 721 | 701 | 172.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
