| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_075T01_9000001726_11713cztM0_level2.evt | modeM0/AS1G08_075T01_9000001726_11713cztM0_level2_quad_clean.evt |
| Size (bytes) | 539,974,080 | 95,607,360 |
| Size | 515.0 MB | 91.2 MB |
| Events in quadrant A | 4,176,042 | 610,655 |
| Events in quadrant B | 4,595,787 | 602,500 |
| Events in quadrant C | 3,246,018 | 607,045 |
| Events in quadrant D | 3,855,556 | 582,463 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16930 | 3 |
| B | 0 | 18107 | 2 |
| C | 0 | 14718 | 2 |
| D | 0 | 16081 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7069 | 199 | 2.815108% |
| B | 7069 | 450 | 6.365823% |
| C | 7069 | 87 | 1.230726% |
| D | 7069 | 144 | 2.037063% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7285 | 7072 | 9 | 9 | 0.12% | 0.13% |  |
| B | 7285 | 7072 | 173 | 173 | 2.37% | 2.45% |  |
| C | 7285 | 7072 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7285 | 7072 | 51 | 51 | 0.70% | 0.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 528662 | 2991.77 | 862 | 843 | 176.4 |
| A | 1 | 162 | 117839 | 663.15 | 862 | 843 | 176.4 |
| A | 1 | 178 | 61060 | 341.32 | 862 | 843 | 176.4 |
| B | 4 | 239 | 791672 | 4823.51 | 845 | 824 | 164.0 |
| B | 10 | 245 | 188406 | 1144.09 | 845 | 824 | 164.0 |
| B | 3 | 64 | 112666 | 682.14 | 845 | 824 | 164.0 |
| C | 13 | 61 | 6147 | 27.28 | 831 | 835 | 194.7 |
| C | 12 | 4 | 3319 | 12.76 | 831 | 835 | 194.7 |
| C | 3 | 202 | 1958 | 5.77 | 831 | 835 | 194.7 |
| D | 4 | 95 | 237078 | 1173.04 | 833 | 812 | 201.4 |
| D | 1 | 52 | 203025 | 1003.97 | 833 | 812 | 201.4 |
| D | 8 | 195 | 148168 | 731.61 | 833 | 812 | 201.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
