| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_006T01_9000001728_11726cztM0_level2.evt | modeM0/AS1G08_006T01_9000001728_11726cztM0_level2_quad_clean.evt |
| Size (bytes) | 654,563,520 | 115,050,240 |
| Size | 624.2 MB | 109.7 MB |
| Events in quadrant A | 6,229,184 | 731,197 |
| Events in quadrant B | 4,684,460 | 764,796 |
| Events in quadrant C | 3,125,045 | 786,222 |
| Events in quadrant D | 5,330,033 | 733,138 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22967 | 2 |
| B | 0 | 18148 | 1 |
| C | 0 | 13823 | 1 |
| D | 0 | 20225 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6722 | 980 | 14.578994% |
| B | 6722 | 413 | 6.144005% |
| C | 6722 | 113 | 1.681047% |
| D | 6722 | 493 | 7.334127% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7618 | 6724 | 702 | 702 | 9.22% | 10.44% |  |
| B | 7618 | 6724 | 189 | 189 | 2.48% | 2.81% |  |
| C | 7618 | 6724 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7618 | 6724 | 376 | 376 | 4.94% | 5.59% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 2714831 | 17367.58 | 783 | 766 | 156.3 |
| A | 1 | 162 | 152364 | 970.09 | 783 | 766 | 156.3 |
| A | 1 | 178 | 85393 | 541.54 | 783 | 766 | 156.3 |
| B | 4 | 239 | 649504 | 4288.1 | 803 | 782 | 151.3 |
| B | 3 | 64 | 309399 | 2039.98 | 803 | 782 | 151.3 |
| B | 15 | 204 | 276086 | 1819.78 | 803 | 782 | 151.3 |
| C | 4 | 222 | 6125 | 29.2 | 798 | 803 | 182.3 |
| C | 13 | 61 | 5858 | 27.73 | 798 | 803 | 182.3 |
| C | 4 | 112 | 3680 | 15.78 | 798 | 803 | 182.3 |
| D | 1 | 52 | 1462938 | 7789.94 | 782 | 761 | 187.7 |
| D | 8 | 195 | 607938 | 3234.82 | 782 | 761 | 187.7 |
| D | 13 | 104 | 50193 | 263.36 | 782 | 761 | 187.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
