| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_113T03_9000001738_11752cztM0_level2.evt | modeM0/AS1A04_113T03_9000001738_11752cztM0_level2_quad_clean.evt |
| Size (bytes) | 780,589,440 | 66,165,120 |
| Size | 744.4 MB | 63.1 MB |
| Events in quadrant A | 3,989,359 | 426,658 |
| Events in quadrant B | 4,366,315 | 432,492 |
| Events in quadrant C | 3,176,336 | 441,267 |
| Events in quadrant D | 11,686,264 | 265,747 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16181 | 3 |
| B | 0 | 16970 | 2 |
| C | 0 | 13181 | 2 |
| D | 0 | 39006 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6243 | 99 | 1.585776% |
| B | 6243 | 285 | 4.565113% |
| C | 6243 | 51 | 0.816915% |
| D | 6243 | 3645 | 58.385392% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7554 | 6245 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7554 | 6245 | 132 | 132 | 1.75% | 2.11% |  |
| C | 7554 | 6245 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7554 | 6245 | 3462 | 3462 | 45.83% | 55.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 468364 | 2846.09 | 817 | 803 | 164.3 |
| A | 1 | 162 | 113357 | 685.13 | 817 | 803 | 164.3 |
| A | 6 | 16 | 73406 | 441.94 | 817 | 803 | 164.3 |
| B | 4 | 239 | 624825 | 4143.72 | 819 | 802 | 150.6 |
| B | 4 | 81 | 321810 | 2131.6 | 819 | 802 | 150.6 |
| B | 15 | 204 | 134699 | 889.12 | 819 | 802 | 150.6 |
| C | 13 | 61 | 6146 | 28.91 | 813 | 819 | 184.3 |
| C | 14 | 67 | 4072 | 17.65 | 813 | 819 | 184.3 |
| C | 12 | 4 | 3053 | 12.12 | 813 | 819 | 184.3 |
| D | 1 | 52 | 9106434 | 68890.49 | 559 | 546 | 132.2 |
| D | 8 | 195 | 173639 | 1309.53 | 559 | 546 | 132.2 |
| D | 13 | 104 | 120712 | 909.11 | 559 | 546 | 132.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
