| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_167T04_9000001734_11742cztM0_level2.evt | modeM0/AS1A04_167T04_9000001734_11742cztM0_level2_quad_clean.evt |
| Size (bytes) | 644,158,080 | 90,311,040 |
| Size | 614.3 MB | 86.1 MB |
| Events in quadrant A | 4,339,759 | 551,628 |
| Events in quadrant B | 5,634,717 | 534,147 |
| Events in quadrant C | 3,560,964 | 574,696 |
| Events in quadrant D | 5,455,339 | 542,630 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17779 | 3 |
| B | 0 | 21638 | 2 |
| C | 0 | 15810 | 2 |
| D | 0 | 21874 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7651 | 325 | 4.247811% |
| B | 7651 | 725 | 9.475886% |
| C | 7651 | 144 | 1.882107% |
| D | 7651 | 265 | 3.463600% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7817 | 7655 | 11 | 11 | 0.14% | 0.14% |  |
| B | 7817 | 7655 | 329 | 329 | 4.21% | 4.30% |  |
| C | 7817 | 7655 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7817 | 7655 | 32 | 32 | 0.41% | 0.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 317100 | 1661.98 | 921 | 901 | 190.3 |
| A | 1 | 162 | 148663 | 776.66 | 921 | 901 | 190.3 |
| A | 1 | 178 | 79874 | 415.09 | 921 | 901 | 190.3 |
| B | 3 | 64 | 1010350 | 5879.44 | 894 | 870 | 171.7 |
| B | 4 | 239 | 810530 | 4715.64 | 894 | 870 | 171.7 |
| B | 15 | 204 | 194155 | 1125.73 | 894 | 870 | 171.7 |
| C | 13 | 61 | 6755 | 27.78 | 911 | 915 | 210.2 |
| C | 8 | 128 | 4289 | 16.05 | 911 | 915 | 210.2 |
| C | 14 | 234 | 3072 | 10.26 | 911 | 915 | 210.2 |
| D | 8 | 195 | 1117939 | 5142.45 | 902 | 874 | 217.2 |
| D | 1 | 52 | 586547 | 2696.17 | 902 | 874 | 217.2 |
| D | 9 | 85 | 86479 | 394.09 | 902 | 874 | 217.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
