| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_058T09_9000001744_11800cztM0_level2.evt | modeM0/AS1G08_058T09_9000001744_11800cztM0_level2_quad_clean.evt |
| Size (bytes) | 604,958,400 | 79,666,560 |
| Size | 576.9 MB | 76.0 MB |
| Events in quadrant A | 4,020,699 | 476,476 |
| Events in quadrant B | 6,378,149 | 457,615 |
| Events in quadrant C | 3,568,487 | 485,681 |
| Events in quadrant D | 3,839,797 | 465,029 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16576 | 3 |
| B | 0 | 23972 | 2 |
| C | 0 | 15768 | 2 |
| D | 0 | 16605 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7585 | 305 | 4.021094% |
| B | 7585 | 963 | 12.696111% |
| C | 7585 | 178 | 2.346737% |
| D | 7585 | 214 | 2.821358% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7731 | 7588 | 5 | 5 | 0.06% | 0.07% |  |
| B | 7731 | 7588 | 340 | 340 | 4.40% | 4.48% |  |
| C | 7731 | 7588 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7731 | 7588 | 20 | 20 | 0.26% | 0.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 163085 | 848.39 | 926 | 903 | 191.2 |
| A | 1 | 162 | 121444 | 630.56 | 926 | 903 | 191.2 |
| A | 1 | 178 | 57114 | 294.04 | 926 | 903 | 191.2 |
| B | 3 | 64 | 1478760 | 8514.51 | 898 | 876 | 173.6 |
| B | 4 | 239 | 618031 | 3555.6 | 898 | 876 | 173.6 |
| B | 10 | 16 | 495088 | 2847.3 | 898 | 876 | 173.6 |
| C | 13 | 61 | 6778 | 27.47 | 914 | 918 | 213.3 |
| C | 14 | 234 | 5563 | 21.77 | 914 | 918 | 213.3 |
| C | 3 | 202 | 2318 | 6.56 | 914 | 918 | 213.3 |
| D | 1 | 52 | 177360 | 750.7 | 900 | 880 | 235.1 |
| D | 9 | 85 | 56570 | 236.89 | 900 | 880 | 235.1 |
| D | 13 | 104 | 55154 | 230.87 | 900 | 880 | 235.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
