| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T01_209T01_9000001758_11882cztM0_level2.evt | modeM0/AS1T01_209T01_9000001758_11882cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,281,280 | 109,080,000 |
| Size | 460.9 MB | 104.0 MB |
| Events in quadrant A | 3,503,240 | 725,056 |
| Events in quadrant B | 3,734,226 | 741,330 |
| Events in quadrant C | 2,913,596 | 725,769 |
| Events in quadrant D | 4,062,614 | 676,870 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14525 | 3 |
| B | 0 | 15247 | 2 |
| C | 0 | 12892 | 2 |
| D | 0 | 16085 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 23 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6227 | 52 | 0.835073% |
| B | 6227 | 164 | 2.633692% |
| C | 6227 | 34 | 0.546009% |
| D | 6227 | 139 | 2.232215% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7523 | 6229 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7523 | 6229 | 87 | 87 | 1.16% | 1.40% |  |
| C | 7523 | 6229 | 17 | 17 | 0.23% | 0.27% |  |
| D | 7523 | 6229 | 107 | 107 | 1.42% | 1.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 355641 | 2354.98 | 746 | 731 | 150.7 |
| A | 1 | 162 | 101817 | 670.75 | 746 | 731 | 150.7 |
| A | 1 | 178 | 53233 | 348.37 | 746 | 731 | 150.7 |
| B | 4 | 239 | 516487 | 3722.0 | 755 | 739 | 138.6 |
| B | 15 | 204 | 112129 | 803.87 | 755 | 739 | 138.6 |
| B | 15 | 33 | 44632 | 316.76 | 755 | 739 | 138.6 |
| C | 0 | 207 | 54868 | 322.75 | 726 | 728 | 167.7 |
| C | 1 | 16 | 26977 | 156.48 | 726 | 728 | 167.7 |
| C | 13 | 61 | 5565 | 28.84 | 726 | 728 | 167.7 |
| D | 8 | 195 | 432911 | 2542.68 | 710 | 690 | 170.0 |
| D | 5 | 222 | 299827 | 1759.77 | 710 | 690 | 170.0 |
| D | 10 | 50 | 204931 | 1201.51 | 710 | 690 | 170.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
