| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_088T05_9000001764_11915cztM0_level2.evt | modeM0/AS1A04_088T05_9000001764_11915cztM0_level2_quad_clean.evt |
| Size (bytes) | 609,289,920 | 81,622,080 |
| Size | 581.1 MB | 77.8 MB |
| Events in quadrant A | 3,674,272 | 501,220 |
| Events in quadrant B | 4,950,529 | 474,408 |
| Events in quadrant C | 3,297,852 | 509,776 |
| Events in quadrant D | 6,038,383 | 481,236 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15772 | 3 |
| B | 0 | 19627 | 2 |
| C | 0 | 14909 | 2 |
| D | 0 | 22763 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7250 | 124 | 1.710345% |
| B | 7250 | 571 | 7.875862% |
| C | 7250 | 47 | 0.648276% |
| D | 7250 | 844 | 11.641379% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7921 | 7251 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7921 | 7251 | 280 | 280 | 3.53% | 3.86% |  |
| C | 7921 | 7251 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7920 | 7250 | 789 | 789 | 9.96% | 10.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 138313 | 784.84 | 857 | 838 | 175.2 |
| A | 1 | 162 | 67444 | 380.25 | 857 | 838 | 175.2 |
| A | 1 | 178 | 33369 | 185.72 | 857 | 838 | 175.2 |
| B | 4 | 239 | 1479533 | 9147.81 | 841 | 819 | 161.6 |
| B | 15 | 204 | 124699 | 766.36 | 841 | 819 | 161.6 |
| B | 10 | 252 | 31371 | 189.0 | 841 | 819 | 161.6 |
| C | 12 | 4 | 9094 | 42.02 | 843 | 851 | 196.2 |
| C | 13 | 61 | 6156 | 27.04 | 843 | 851 | 196.2 |
| C | 3 | 202 | 2023 | 5.97 | 843 | 851 | 196.2 |
| D | 1 | 52 | 2269197 | 11967.46 | 780 | 756 | 189.6 |
| D | 8 | 195 | 219037 | 1151.57 | 780 | 756 | 189.6 |
| D | 5 | 222 | 156098 | 819.53 | 780 | 756 | 189.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
