| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_088T05_9000001764_11922cztM0_level2.evt | modeM0/AS1A04_088T05_9000001764_11922cztM0_level2_quad_clean.evt |
| Size (bytes) | 526,872,960 | 100,247,040 |
| Size | 502.5 MB | 95.6 MB |
| Events in quadrant A | 3,975,017 | 650,241 |
| Events in quadrant B | 4,104,843 | 643,973 |
| Events in quadrant C | 3,071,733 | 653,438 |
| Events in quadrant D | 4,350,874 | 621,605 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16234 | 3 |
| B | 0 | 16491 | 2 |
| C | 0 | 13730 | 2 |
| D | 0 | 17157 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6693 | 122 | 1.822800% |
| B | 6693 | 204 | 3.047961% |
| C | 6693 | 43 | 0.642462% |
| D | 6693 | 239 | 3.570895% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7709 | 6694 | 6 | 6 | 0.08% | 0.09% |  |
| B | 7709 | 6694 | 117 | 117 | 1.52% | 1.75% |  |
| C | 7709 | 6694 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7709 | 6694 | 176 | 176 | 2.28% | 2.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 367036 | 2205.06 | 812 | 795 | 166.1 |
| A | 1 | 162 | 135345 | 810.1 | 812 | 795 | 166.1 |
| A | 14 | 63 | 114953 | 687.32 | 812 | 795 | 166.1 |
| B | 4 | 239 | 695734 | 4509.56 | 802 | 782 | 154.1 |
| B | 15 | 204 | 178179 | 1151.13 | 802 | 782 | 154.1 |
| B | 0 | 231 | 25085 | 157.7 | 802 | 782 | 154.1 |
| C | 13 | 61 | 5826 | 27.52 | 788 | 792 | 182.9 |
| C | 3 | 202 | 1966 | 6.42 | 788 | 792 | 182.9 |
| C | -1 | -1 | -1 | -1.0 | 788 | 792 | 182.9 |
| D | 1 | 52 | 470723 | 2510.32 | 786 | 764 | 187.2 |
| D | 8 | 195 | 341908 | 1822.24 | 786 | 764 | 187.2 |
| D | 10 | 199 | 289811 | 1543.97 | 786 | 764 | 187.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
