| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A04_082T01_9000001772_11980cztM0_level2.evt | modeM0/AS1A04_082T01_9000001772_11980cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,025,625,600 | 186,500,160 |
| Size | 978.1 MB | 177.9 MB |
| Events in quadrant A | 6,618,119 | 1,212,524 |
| Events in quadrant B | 8,708,680 | 1,193,183 |
| Events in quadrant C | 5,961,182 | 1,194,405 |
| Events in quadrant D | 8,878,773 | 1,134,645 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 270 | 0 |
| B | 0 | 270 | 0 |
| C | 0 | 270 | 0 |
| D | 0 | 270 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28480 | 4 |
| B | 0 | 34581 | 3 |
| C | 0 | 27112 | 3 |
| D | 0 | 35524 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27 | 0 |
| B | 0 | 27 | 0 |
| C | 0 | 27 | 0 |
| D | 0 | 27 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 13226 | 254 | 1.920460% |
| B | 13226 | 850 | 6.426735% |
| C | 13226 | 149 | 1.126569% |
| D | 13226 | 986 | 7.455013% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 15912 | 13227 | 10 | 10 | 0.06% | 0.08% |  |
| B | 15912 | 13227 | 438 | 438 | 2.75% | 3.31% |  |
| C | 15912 | 13227 | 0 | 0 | 0.00% | 0.00% |  |
| D | 15912 | 13227 | 716 | 716 | 4.50% | 5.41% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 194662 | 610.66 | 1576 | 1542 | 316.2 |
| A | 1 | 178 | 91672 | 285.0 | 1576 | 1542 | 316.2 |
| A | 1 | 161 | 82046 | 254.56 | 1576 | 1542 | 316.2 |
| B | 4 | 239 | 1966185 | 6608.29 | 1553 | 1514 | 297.3 |
| B | 3 | 64 | 360920 | 1208.88 | 1553 | 1514 | 297.3 |
| B | 15 | 204 | 157600 | 525.0 | 1553 | 1514 | 297.3 |
| C | 13 | 61 | 11080 | 26.92 | 1528 | 1531 | 354.8 |
| C | 14 | 234 | 3944 | 6.8 | 1528 | 1531 | 354.8 |
| C | 3 | 202 | 3735 | 6.21 | 1528 | 1531 | 354.8 |
| D | 1 | 52 | 2628430 | 7478.67 | 1473 | 1429 | 351.3 |
| D | 8 | 195 | 214684 | 607.1 | 1473 | 1429 | 351.3 |
| D | 5 | 222 | 124873 | 351.42 | 1473 | 1429 | 351.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
