| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_065T01_9000001796_12133cztM0_level2.evt | modeM0/AS1G08_065T01_9000001796_12133cztM0_level2_quad_clean.evt |
| Size (bytes) | 685,995,840 | 103,999,680 |
| Size | 654.2 MB | 99.2 MB |
| Events in quadrant A | 6,299,039 | 653,408 |
| Events in quadrant B | 6,439,261 | 638,398 |
| Events in quadrant C | 3,412,203 | 683,286 |
| Events in quadrant D | 4,121,845 | 656,895 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23959 | 3 |
| B | 0 | 24217 | 2 |
| C | 0 | 15398 | 2 |
| D | 0 | 17440 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7433 | 710 | 9.551998% |
| B | 7433 | 1074 | 14.449078% |
| C | 7433 | 23 | 0.309431% |
| D | 7433 | 184 | 2.475447% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7674 | 7435 | 522 | 522 | 6.80% | 7.02% |  |
| B | 7674 | 7435 | 586 | 586 | 7.64% | 7.88% |  |
| C | 7674 | 7435 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7674 | 7435 | 64 | 64 | 0.83% | 0.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 63 | 2820252 | 16176.84 | 856 | 837 | 174.3 |
| A | 1 | 162 | 62055 | 351.25 | 856 | 837 | 174.3 |
| A | 1 | 178 | 29740 | 165.84 | 856 | 837 | 174.3 |
| B | 4 | 239 | 1481763 | 9286.03 | 836 | 815 | 159.5 |
| B | 10 | 16 | 618668 | 3874.14 | 836 | 815 | 159.5 |
| B | 3 | 64 | 592022 | 3707.06 | 836 | 815 | 159.5 |
| C | 13 | 250 | 8349 | 37.14 | 871 | 874 | 201.2 |
| C | 13 | 61 | 6567 | 28.29 | 871 | 874 | 201.2 |
| C | 14 | 234 | 5697 | 23.97 | 871 | 874 | 201.2 |
| D | 1 | 52 | 259221 | 1247.12 | 861 | 836 | 207.2 |
| D | 8 | 195 | 146409 | 702.62 | 861 | 836 | 207.2 |
| D | 13 | 104 | 122298 | 586.25 | 861 | 836 | 207.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
