| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G08_065T01_9000001796_12156cztM0_level2.evt | modeM0/AS1G08_065T01_9000001796_12156cztM0_level2_quad_clean.evt |
| Size (bytes) | 528,278,400 | 81,645,120 |
| Size | 503.8 MB | 77.9 MB |
| Events in quadrant A | 3,509,027 | 525,987 |
| Events in quadrant B | 5,458,883 | 470,315 |
| Events in quadrant C | 3,173,233 | 513,971 |
| Events in quadrant D | 3,410,831 | 502,280 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14528 | 3 |
| B | 0 | 20661 | 2 |
| C | 0 | 13640 | 2 |
| D | 0 | 14322 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6588 | 109 | 1.654523% |
| B | 6588 | 768 | 11.657559% |
| C | 6588 | 57 | 0.865209% |
| D | 6588 | 83 | 1.259866% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7799 | 6589 | 14 | 14 | 0.18% | 0.21% |  |
| B | 7799 | 6590 | 515 | 515 | 6.60% | 7.81% |  |
| C | 7799 | 6589 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7799 | 6589 | 29 | 29 | 0.37% | 0.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 1 | 162 | 95561 | 552.17 | 853 | 837 | 171.5 |
| A | 1 | 178 | 38182 | 217.69 | 853 | 837 | 171.5 |
| A | 1 | 161 | 35897 | 204.37 | 853 | 837 | 171.5 |
| B | 0 | 85 | 687727 | 4670.67 | 791 | 774 | 147.1 |
| B | 4 | 239 | 657204 | 4463.14 | 791 | 774 | 147.1 |
| B | 15 | 201 | 527881 | 3583.86 | 791 | 774 | 147.1 |
| C | 3 | 233 | 6620 | 31.21 | 812 | 816 | 186.0 |
| C | 13 | 61 | 6056 | 28.18 | 812 | 816 | 186.0 |
| C | 15 | 208 | 3342 | 13.58 | 812 | 816 | 186.0 |
| D | 1 | 52 | 105373 | 540.76 | 817 | 797 | 193.4 |
| D | 10 | 157 | 43432 | 220.47 | 817 | 797 | 193.4 |
| D | 7 | 71 | 35216 | 177.98 | 817 | 797 | 193.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
